Steps To Replace The Lamp - InFocus IN42 Replacement Instructions

4 Loosen the three captive screws (marked by the arrows) on the lamp
module.
5 Carefully remove the lamp module by grasping and lifting the handle.
Dispose of the lamp in an environmentally proper manner.
6 Install the new lamp module, making sure that it is properly seated, and
tighten the three captive screws.
7
Replace the cover over the lamp module by sliding it back into place and
tightening the screw.
8 Plug in the power cable, press the power switch then press the Power
button to turn the projector back on. Reset the lamp hour timer by navi-
gating to the Settings>Service menu and selecting Reset Lamp Hours.
loosen the captive screws on lamp module
lamp module handle
35
reset lamp hours in Service menu
