InFocus IN42 Communication Configuration

RS-232C communication
Communication Configuration
To control this projector via RS-232, connect a null modem cable and set the control system serial port
settings to match the following communication configuration:
Setting
Bits per second
Data bits
Parity
Stop bits
Flow control
Emulation

Command Format

All commands consist of 3 alpha characters followed by a request, all enclosed in parentheses. The request
can be a read request (indicated by a "?") or a write request (indicated by 1 to 4 ASCII digits).
A read request example:
(AAA?) where
(starts the command
AAA denotes the command
? denotes the read request)
ends the command
A read command returns the range and the current setting, for example:
Read Command Examples
Function
Brightness
Volume
Lamp Hours
A write request example:
(AAA####) where
(starts the command
AAA denotes the command
#### denotes the value to be written
(leading zeros not necessary)
) ends the command
Some commands have ranges, while others are absolute. If a number greater than the maximum range is
received, it is automatically set to the maximum number for that function. If a command is received that is not
understood, a "?" is returned. With absolute settings, "0" is off, 1-9999 is on. The one excep-tion is the Power
command, where 0 is off and 1 is on.
To assure the projector can process a command, wait 3 seconds before enter-ing the next command.
IN42 / C445
RS-232 Port Settings
Value
19,200
8
None
1
None
VT100
Command
(BRT?)
(VOL?)
(LMP?)
Response
(96-160, 128)
(0-32, 0)
(0-32766, 42)
