7.
Remove the six (6) 5/16" Cap Screws, Lockwashers and Hex Nuts from the
left and right Hub Sleeves.
8.
CAREFULLY remove Hub Sleeves, one at a time, from the Frame.
9.
The Impactor can now be moved to a clean, sturdy workbench to be
disassembled for required maintenance and/or repair.
IMPORTANT
Support the 125 lb. Impactor properly when
removing it from the Frame. Failure to properly
support the Impactor could result in injury.
To reinstall Impactor into Cart Frame, reverse
the above procedure making sure the
Impactor's Head Handle is positioned between
the Frame's rear parallel Tubes.
PH: 866.476.9217
8
