STEP 1.
ASSEMBLING YOUR NEW SPRAYER
Required tools: Phillips head screwdriver
Before you begin, open the tank lid (1) and
A)
remove the nuts and bolts, holsters, and
nozzles from inside the tank strainer (3). Set
aside.
Bring the ComfortStraps™ (5) to the bottom
B)
of the tank (2). Secure lower strap clips to
the tank loops near the bottom of the tank.
Next, slide the adjustable strap through the
C)
top tank loop. Continue by sliding the strap
over and under the buckle fitting. Lightly tug at
the strap to make sure it's secure. Repeat on
other side.
Place the top wand holster (4) on the molded
D)
holster bracket on the tank. While holding
the holster, place nut on one side of the
hexagonal slots and screw the bolt through
the other side until it fastens into the nut.
10
Repeat for other slot and bottom holster.
E)
Take the spray gun (8) and attach it to the
threaded fitting on the end of the hose (7).
Tighten the fitting to ensure the gasket
properly seals the connection.
If spraying with the stainless-steel spray
F)
wand (6), pull back on the collar of the
quick-connect fitting on the spray gun. Insert
the male wand fitting into the female spray
gun fitting and push the collar back into its
original position. Nozzles can be attached
with the same process.
G)
Snap the spray wand into the wand holster
and place any unused nozzles into their slot
until ready to spray.
