X-Stream CLEAN Volt XCMADD Operation Manual

Electrostatic sprayer

Hide thumbs

Table of Contents

Quick Links

Download this manual

CLEAN WITH

ELECTROSTATIC SPRAYER

CONFIDENCE

Operation Guide

Model: XCEAHV

Table of Contents

Need help?

Do you have a question about the Volt XCMADD and is the answer not in the manual?

Questions and answers

Summary of Contents for X-Stream CLEAN Volt XCMADD

Page 1 CLEAN WITH ELECTROSTATIC SPRAYER CONFIDENCE Operation Guide Model: XCEAHV...
Page 2 WARNINGS ......................SAFETY ......................REGISTER YOUR SPRAYER ......................SPRAYER CAPABILITIES ......................WHAT’S IN THE BOX ......................Copyright ©WESSOL, LLC...
Page 3 ASSEMBLY & SPRAYING ......................BATTERY CHARGING ......................PARTS & ACCESSORIES ......................TROUBLESHOOTING ......................WARRANTY POLICY ......................Copyright ©WESSOL, LLC...
Page 4 Do not store your sprayer in extremely high temperatures. Heat can lead to the build-up of pressure within the sprayer, resulting in a possible explosion. • Do not try to make modifications to the sprayer. Always use X-Stream Clean branded replacement parts from the manufacturer.
Page 5 SAFETY & PRECAUTION Please read the following information carefully. User must read and understand entire manual before operating this sprayer. Improper use or failure to follow instructions could lead to sprayer failure and possible serious injuries. SAFETY • Use the sprayer and accessories in accordance with these instructions, taking into consideration the working conditions and the work to be performed. Use of this sprayer for applications that it was not intended for could result in a hazardous situation.
Page 6 Always use the correct power setting for your application. Using the correct PSI and flow-rate will result in a safer and more thorough treatment. For calibration resources please contact X-Stream Clean technical support. (Note: Always refer to local, state, and federal laws and regulations regarding your application.) ®...
Page 7 SAFETY & PRECAUTION Please read the following information carefully. User must read and understand entire manual before operating this sprayer. Improper use or failure to follow instructions could lead to sprayer failure and possible serious injuries. WORK AREA • Keep work area clean and well lit. Cluttered or dark areas invite accidents. •...
Page 8 REGISTER YOUR SPRAYER! To take advantage of the 1-year Limited Warranty from WESSOL, LLC. Register your sprayer at the website below: xstreamclean.com/register LET’S Please read and follow this manual carefully to ensure that you get the most out of your new sprayer. If you need assistance with the assembly or operation of your sprayer, please don’t hesitate to contact WESSOL via the support methods below: xstreamclean.com...
Page 9 1-Liter electrostatic sprayer is a highly efficient battery powered backpack sprayer for the ® ™ toughest cleaning, sanitation, and decontamination jobs. Introducing the all-new Volt 1-Liter Electrostatic Backpack sprayer by X-Stream Clean ! Designed to make sanitation & decontamination projects faster and easier, the ™ ® Volt can spray for up to 6 hours with a lightweight spray gun.
Page 11 ELECTROSTATIC SPRAY GUN 21V/2.5A BATTERY CHARGER PART NUMBER: XCAAHT PART NUMBER: FZAAEL 1L VOLT TANK NOZZLE WRENCH ™ PART NUMBER: XCRALB PART NUMBER: XCAAJG TANK LID 40-MICRON STAINLESS-STEEL MISTING NOZZLE PART NUMBER: XCRALH PART NUMBER: XCAAKF 80-MICRON STAINLESS-STEEL MISTING NOZZLE COMFORTSTRAPS 1L HIP STRAPS ™...
Page 12: Assembling Your Sprayer
STEP 1. ASSEMBLING YOUR SPRAYER Before you begin, locate the 40-micron misting nozzle (9), 120-micron misting nozzle (11) and nozzle wrench (8), can be found in the gun box, and set aside. Take the electrostatic gun (1) and attach it to the *The 80-micron misting nozzle (10) is pre-installed in the gun threaded fitting on the end of the hose (5).
Page 13: Preparing To Spray
STEP 2. PREPARING TO SPRAY Fully charge the battery (6) before the first operation. Turn pump on by flipping switch on side of unit. Indicator lights will flash as the battery is charging. In a separate container, prepare the solution you want I | Indicates Pump is On to spray according to the manufacturer’s instructions.
Page 14 STEP 3. AFTER YOU FINISH SPRAYING Dispose extra liquid/chemical based Store the sprayer in a clean, dry, and shaded location to manufacturer’s instructions. Rinse out any residual protect it from extreme heat or frost. solution in the spray tank with warm, soapy water. Then spray fresh water through the sprayer for 3 to 5 minutes to completely clear the tank, pump, gun, wand, and any used nozzles of chemicals.
Page 16 CHARGING BATTERY Please read the following information carefully. User must read and understand entire manual before operating this sprayer. Improper use or failure to follow instructions could lead to sprayer failure and possible serious injuries. These batteries have been designed to provide maximum trouble-free life. However, like all batteries, they will eventually wear out. Do not disassemble battery pack and attempt to replace the batteries.
Page 17 CHARGING THE BATTERY Please read the following information carefully. User must read and understand entire manual before operating this sprayer. Improper use or failure to follow instructions could lead to sprayer failure and possible serious injuries. BATTERY RECYCLING PREPARATION • To preserve natural resources, please recycle or dispose of the batteries properly.
Page 18: Replacement Parts
ACCESSORY & REPLACEMENT PARTS XC A AH T XCR AKV XC RAKW XC RALH Electrostatic Spray Gun ComfortStraps 1L Hip Straps ComfortStraps 1L Backpack Tank Lid ™ - ™ - with Turbo-Boost ™ XC RALN FZA AEM F ZAAE L XC RALJ 5’...
Page 19 ACCESSORY & REPLACEMENT PARTS XC R ALG XC RALI XC RAJK XC AAKJ Recirculating Diaphragm Pump Viton 1-Liter Tank Lid Gasket DC-to-DC ESD Grounded Foot Strap ™ Voltage Converter XC A A J G XCA AKF XC AAKG XC AAKH Nozzle Wrench 40-Micron Stainless-Steel 80-Micron Stainless-Steel...
Page 20: Troubleshoot
TROUBLESHOOT YOUR SPRAYER PROBLEM POSSIBLE REASON(S) SOLUTION Charge the battery. If the battery will not charge, test the charger or call Support at +1 803.339.2500 Dead battery for a replacement if applicable. Sprayer is not turning Loose/worn connections on power Remove back cover plate.
Page 21 TROUBLESHOOT YOUR SPRAYER PROBLEM POSSIBLE REASON(S) SOLUTION Not rinsing tank / pump / hose / Clogged pump / hose gun / nozzle(s) with water after Rinse sprayer throughly with warm, soapy water after each use. / gun / wand / nozzle. use.
Page 23: Warranty
PRODUCT REGISTRATION All purchases from X-Stream Clean® or an authorized distributor must be registered online to validate the warranty and allow for warranty claim processing. Follow the link below to register your spray mop. EXCLUSIONS AND LIMITATIONS WESSOL, LLC only warrants products purchased from authorized distributors. Products purchased from unauthorized resellers or distributors are not subject to warranty services. The limited warranty does not cover damages, loss, or injury resulting from transportation, storage, accident, improper use, neglect, modifications, normal wear, or operation not in accordance with the instruction manual.

This manual is also suitable for:

Volt 2.5g xceahx
