Q
S
UICK
TART
INTRODUCTION
Thank you for purchasing the ikan VH7 LCD Monitor. We know that you will be satisfied with our "V" series monitors.
Please visit www.ikancorp.com for more information on our current and future products including our award-winning
fluorescent studio lights and light accessories.
PACKAGE INCLUDES
VH7 LCD Monitor
AC Power Adapter
Camera Shoe Mount
Battery Adapter
(check one)
MONITOR DIAGRAMS
Front view
MENU
Menu
Volume
Volume
Bottom view
BUTTON FUNCTIONS
Volume Buttons
1
Decreases and increases volume aswell as toggle through menu.
Menu Button
2
It is to display brightness, contrast, phase, clock, H position,
V position, language, auto, reset, volume, exit.
Input Button
3
Video selectionswitch AV1, AV2,VGA, HDMI
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period has expired.
Free Service will not be Provided in the Following Situations:
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.
3903 Stoney Brook Dr. Houston TX 77063. 1-713-272-8822, support@ikancorp.com © 2009 ikan Corporation. All right reserved. www.ikancorp.com
G
UIDE /
VH7 7" HDMI LCD MONITOR
VGA Cable
Remote Control
2 x Composite Female RCA Cable
: [ BP2T-S ] [ BP2T-SU ] [ BP2T-C ] [ BP2T-P ]
INPUT
ASPECT
Input Aspect Power
¼-20 Threaded Hole
VGA
Composite
DC 5V-24V
VIDEO 1
Back view
DC
VGA
5V-24V
+
PC Audio
Composite
VIDEO 2
4
ASPECT Selection Button
Aspect: 16:9, 4:3, Full
Power Button
5
Turns monitor on and off
(* Even if the product is still within the warranty period.)
Checked by
VGA TFT LCD MONITOR
Model: VG7
Picture Size: 7 inch
Resolution: 800x480
ikan corp.
Aspect Ratio: 16:9 / 4:3
www.ikancorp.com
Color System: NTSC/PAL
Signal Input: VGA/Composite
VIDEO 1
HDMI
VIDEO 2
+
+
+
+
HDMI
Mounting Plate Holes
Audio input for headphones
PC
+
AUDIO
