nystrom HRVE55C Installation, Operation And Maintenance Manual

5-1/2" CRASH RESISTANT HANDRAIL
Model(s):HRVE55C/HRVE55C-TG/HRVE55C-AS

GENERAL DESCRIPTION

Introduction + Safety

Please read the complete instructions carefully before beginning any work. To ensure proper
installation and performance of the Expansion Joint, the following actions must be completed
by the installing contractor. Failure to do so will affect product warranty.
GENERAL SAFETY PRECAUTIONS
is solely the responsibility of the user, through its own analysis to select products suitable for their specific application
requirements, ensure they are properly maintained, and limit their use to its intended purpose. Follow proper local,
state and federal regulations for proper installation and operation requirements.

Transportation + Storage

o Inspect all shipments and materials for missing or damaged components and hardware.
o Material must be stored in a clean, dry location.

INSTALLATION

1. Lay out the work to be completed, including all component parts, along the base of the wall. Check the
material for any damage that may have occurred during shipment and/or handling at the job site.
2. Snap a chalk line at the proper location on the wall to ensure a level installation. Chalk line should be
calculated to the center line of the mounting bracket wall fasteners.
Nystrom's Standard 5-1/2" Handrail is constructed to withstand
impact with built-in crash protection. The sturdy mounting brackets
maintain wall clearance and stability while providing support in
medium- to high-impact areas. End and corner caps are available as
semi-rigid plastic. Optional reveals, available for both foam cushion
and semi-rigid plastic end and corner caps, provide additional design
options.
Improper selection, installation, or use can cause personal injury or property damage. It
Installation, Operation
+ Maintenance Manual
©2020 Nystrom, Inc.
1
REV 9/2020
