INSTRUCTION MANUAL
FOR
DUST SWITCH
Model:PFM-DWS10
Contents
TDSW-001E
Rev1:2013.02.28
1
2
2
3
4
6
7
9
Advertisement
Table of Contents
Related Manuals for Matsushima PFM-DWS10
Summary of Contents for Matsushima PFM-DWS10
-
Page 1: Table Of Contents
TDSW-001E Rev1:2013.02.28 INSTRUCTION MANUAL FOR DUST SWITCH Model:PFM-DWS10 Contents Safety Precautions 1. Introduction 2. Specification 3. Dimension Drawing 4. Installation 5. Wiring 6. Operation 7. Troubleshooting ※An operator should read carefully this instruction manual and conduct correct handing. 1-8-18 Norimatsu-Higashi,Yahatanishi-ku,Kitakyushu 807-0837 Japan Phone No.(8193)691-3731 Fax No.(8193)691-3735 http://www.matsushima-m-tech.com E-mail sales@matsushima-m-tech.com ... -
Page 2: Safety Precautions
Cause for any peripheral equipment or device. d. Accident beyond control and force majeure (fire, earthquake, flood, riots, etc.). Lack of instructions to MATSUSHIMA for information or safety requirements that can be predicted only by customers’ side. This warranty conditions do not limit customers’ legal right. -
Page 3: Introduction
1. Introduction This dust switch can be installed on small or medium-sized dust collectors and detects dust discharged from the dust collector. Dust particles coming in contact with or passing near the electrode of the switch cause an electric charge to transfer from the dust particles to the electrode. The dust switch detects this transfer of electric charge and outputs ON/OFF signals. -
Page 4: Dimension Drawing
3. Dimension Drawing Fig. 1 External Dimensions - 3 -... -
Page 5: Installation
4. Installation The dust switch must be installed horizontally or vertically. ・ A: The Isolation must protrude at least 10 mm from the side wall of the duct. ・ B: The distance between the probe tip and the side wall of the duct must be at least 10 mm. Fig. - Page 6 ●Installation example to Dust Collector Prepare a duct for installing Dust Switch to the Exhaust port of Dust Collector. If Dust Switch is installed to this duct, it is possible to deduct the filter breakage of Dust Collector in the early stage. Exhaust Exhaust air duct port...
-
Page 7: Wiring
5. Wiring 5-1. Wiring Connections Before wiring, be sure to confirm that the power supply has been turned off. Failure to observe this instruction may result in an electric shock, electric leakage, fire or other such accident. Use shielded pair cable: 0.32 mm to 0.65 mm in diameter x 2. The cable length should be no more than 100 m taking into consideration the voltage drop. -
Page 8: Operation
6. Operation 6-1. Parts Arrangement The names and layout of the parts on the board are as shown in the figure below. ① ② ③ ... - Page 9 6-2. Adjustment 1) Sensitivity adjusting volume The sensitivity adjusting volume is used to adjust the detection sensitivity according to the environment. The setting range is 0 to 10. The detection sensitivity decreases as the volume is turned counterclockwise toward 0, and increases as turned clockwise toward 10. ...
-
Page 10: Troubleshooting
7. Troubleshooting If the problem cannot be solved by taking the applicable actions, please contact Matsushima Machinery Laboratory. Table 3 Troubleshooting Problem Probable cause Items to be checked 1) Power is not supplied. 1) Check wiring connections. ・Power indicator 2) Power supply Specification differ from what...
