3. Technical specifications

Telescope
Arm
Batteries
Side-wheel (front
and rear)
Picture 2, parts of the robot

Technical data, EVO Cleaner

Total width:
Total length:
Total height when retracted: 1610 mm
Max reach of arm:
Effective working range:
Weight:
Power supply:
Electric motors:
Ambient temp:
Storing temp.:
Control system:
Alarm:
Water supply:
Nozzle:
Hose reel:
Recommended water
pressure:
Recommended water flow: 15-18 l/min

Accessories

Charger:
Markers:
Nozzle:
Boom
Nozzle
Tower
Transport wheel
680 mm (with special wheels, 600 mm)
2100 mm (incl. guidance wheel)
4015 mm
up to 6000 mm from centre of unit
270 kg
24 V DC (2 lead acid batteries at 12 V)
24 V DC (7 in total)
1°C to 55°C (33.8°F - 131°F)
Empty of water, -10°C to +75C (14°F - 167°F)
Horner PLC
Alarm by SMS in the event of operational breakdown.
From external high-pressure cleaning unit
Rotor jet 0.55
50 m high pressure hose (operated separately from the robot).
Connected to a normal cleaning unit.
180-210 bar (18-21MPa)
see separate specifications supplied with the charger
design and quantity are dependent on the installation
alternative nozzles may be available depending on the working area.
Connector
joystick
Clutch handle
Magnet-switch
3
Operator panel
Connector
charger
Hose reel
400º
6 m incl. water jet
Picture 3, the reach of the arm
