USER MANUAL
AFTER SALES SUPPORT:
WWW.SPTOOLS.COM
IMPORTANT
ALL PERSONS WHO ARE TO USE THIS EQUIPMENT MUST THOROUGHLY READ
AND UNDERSTAND THIS INSTRUCTION MANUAL PRIOR TO OPERATION.
SP61060
BATTERY
ANALYSER
(100- 2000 CCA)
RETAIN THESE INSTRUCTIONS
AND ATTACH RECEIPT TO
MANUAL FOR FUTURE
NOTE: Proof of purchase must be retained by
the customer as it will be required in the
event of a claim under warranty.
AUSTRALIA: Visit the website's contact page to get in
touch with your local service department.
INTERNATIONAL: Use the county selector to get in touch
with your service department in your country or region.
REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP61060 and is the answer not in the manual?

Questions and answers

Related Manuals for SP tools SP61060

Summary of Contents for SP tools SP61060

  • Page 1 USER MANUAL SP61060 BATTERY ANALYSER (100- 2000 CCA) RETAIN THESE INSTRUCTIONS AND ATTACH RECEIPT TO MANUAL FOR FUTURE REFERENCE NOTE: Proof of purchase must be retained by the customer as it will be required in the event of a claim under warranty.

  • Page 2: Table Of Contents

    1. Product Summary 1.1 Product Profile The SP61060 Battery Tester adopts what is currently the world's most advanced conductance testing technology available. To easily, quickly and accurately measure the actual cold cranking amps capability of a vehicles starting battery and the health state of the battery itself. This will assist maintenance personnel find problems quickly and accurately, thus reducing vehicle repair times.

  • Page 3: Technical Parameters

    1.2 Product Function The battery test is targeted to analyse the battery’s health status, by calculating the actual cold cranking capability of the battery and the effect of aging. The tester provides reliable analysis of a battery’s condition and notifies the user to replace a battery in advance of its ultimate failure.

  • Page 4: Tester Components

    Tester Components 2.1 Tool Description 1. LCD DISPLAY -- Indicates test results. It is a backlit 2-line display with 8 characters on each line. 2. ENTER BUTTON -- Confirms a selection (or action) from a menu list, or returns to the main menu. 3.

  • Page 5: Battery Explanation's

    2. 3 Battery Voltage Explanation Normally It is impossible for the battery voltage to show as 100%. The max value is 98% even after just being charged. • 98% Charged = Battery voltage Above 12.59v • 75% Charged = Battery voltage 12.45v •...
  • Page 6 3.2 Tester Start-up Tester automatically starts up after the clamps are BATTERY TOOL correctly connected and displays the BAT TOOL start-up Ver 1.00 interface. After 2seconds, it automatically enters the battery test program. 3.3 Battery Test MENU: 1. Enter the main menu, there are two sub-menus: ANALYZER ANALYZER and LANGAUGE, as below, they can shift by pressing SCROLL button...
  • Page 7 3.3.2 Battery System Standard and Rating STANDARD Use "SCROLL" to choose the type of battery; CCA, DIN, JIS, EN, IEC, GB, SAE, MCA, BCI, CA. Then push the "ENTER" button. Look for the marked Rating System Standard on the battery and input its rated capacity by using the SCROLL button.
  • Page 8 Rating range as follows: Battery Range Measured Standard 100-2000 100-2000 100-2000 100-2000 26A17--245H52 100-1400 100-1400 100-2000 100-2000 100-1400 Choose the right standard, press ENTER, then will come to this menu. RATED 500A CCA The SCROLL button will increase or reduce display by 5 units, press repeatedly until the right battery capacity is reached.

  • Page 9: Additional Functions

    3.3.3 Test result In a few seconds, the results of the testing will be displayed in endless rotation on the LCD screen (Holding the scroll button down will halt the rotation). 12.52 V INTERNAL 470 CCA R = 6.3 mΩ 100% OF HEALTHY CHARGE...

  • Page 10: Appendix

    3. 4.2 Appendix: 26A17L 115D31L 26A19L 95E41L 30A19L 100E41L 34A19L 105E41L 26B17L 110E41L 28B17L 115E41L 28B19L 120E41L 34B17L 130E41L 34B19L 115F51 36B20L 130F51 38B19L 145F51 38B20L 150F51 40B19L 170F51 42B19L 145G51 44B19L 155G51 44B20L 165G51 46B24L 180G51 50B24L 195G51 55B24L 190H52 60B24L 210H52...

  • Page 11: Warranty Details

    To the extent permitted by law and subject to this Limited Warranty, and as part of the terms of the sale of the equipment or part thereof: SP Tools shall not be liable for any form of loss, damage, cost, injury or harm of any kind (whether direct, indirect, special or consequential) howsoever arising from the use or supply of the equipment to the purchaser.
