- Page 1 IR Night Vision Binoculars User Manual Model: NV3182 Customer Service Email: support@dsoon-tech.com Please contact us if you have any questions...
- Page 2 Contact Us Via: support@dsoon-tech.com Please contact us if you have any questions...
-
Page 3: Table Of Contents
Contact Us Via: support@dsoon-tech.com Contents ◆ Product Overview ..............5 1) Key Guide ................. 5 2) Specifications ..............7 ◆ Installation................9 1) Install Battery ..............9 2) Inserting Memory Card ............ 9 3) Formatting Memory Card ..........10 ◆ Function & Operation............11 1) Turn On and Turn Off…………………………………………………...11... - Page 4 Contact Us Via: support@dsoon-tech.com 6) Turn On IR…………………………………………………………………….15 7) Shoot Video/Photo………………………………………………………18 8) Menu Setting……….…………………….………………………………..18 9) Playback Video/Photo……………………………………………..…..21 10) Delete& Lock……………………………………………………………..22 11) Unclear Image Reasons………………………………………………23 ◆ Download files to PC ............26 ◆ Maintenance ..............27 ◆ WARRANTY ................. 28 ◆ FAQ ..................29...
-
Page 5: Product Overview
Contact Us Via: support@dsoon-tech.com ◆ Product Overview Key Guide Please contact us if you have any questions... - Page 6 Contact Us Via: support@dsoon-tech.com 2. USB port/Micro SD 1. Focus Wheel card slot Cover 3. IR Up/Zoom in/Up 4. IR Down/Zoom Button out/Down Button 5. Power Button 6. Strap Hole 7. IR LEDs 8. Menu Button 9. Mode Button 10. Shot Button 11.
-
Page 7: Specifications
Contact Us Via: support@dsoon-tech.com Specifications Still Image Size: 1M(1280x960)/VGA(640x480) 960P (1280x960@30FPS) / Video Size: VGA(640x480@30FPS) Aperture: F 1.2 f=25mm Lens Angle: FOV=10°, diameter is 24mm Inner screen 2.31”(960*240) TFT, Display Screen: Outer screen 98*48mm, 3x optical amplification Digital Zoom: Storage Media:... - Page 8 Contact Us Via: support@dsoon-tech.com in weak light: IR LED: 3W, 850nm USB Port: Micro USB 2.0 Power Source: 9V, 6xAA Operating -20℃ to +60℃ Temperature: Storage -30℃ to +70℃ Temperature: Dimension: approx.196*146*59mm Weight: approx.576g Please contact us if you have any questions...
-
Page 9: Installation
Contact Us Via: support@dsoon-tech.com ◆ Installation Install Battery Please install batteries into the device before using. Open the battery cover（11） on the back of the device. Insert 6 x 1.5V AA brand Alkaline batteries into the battery compartment. Make sure the polarity is correct. -
Page 10: Formatting Memory Card
Contact Us Via: support@dsoon-tech.com To remove the card from the memory card slot, press the edge of the memory card gently, the card will pop out. Then remove the card. Note: The device will prompt 'Please insert SD Card' if the TF card is not being installed. -
Page 11: Function & Operation
Contact Us Via: support@dsoon-tech.com attention to backup! Function & Operation Turn On and Turn OFF Long press the POWER button(5) for 3 seconds to turn on the device. Long press the POWER button(5) to turn off the device. Changing The Modes... -
Page 12: Three Modes
Contact Us Via: support@dsoon-tech.com and playback mode. Press the Mode button(9) to change mode. Three Modes Photo Mode For taking still images. Video Mode For recording video (Without Sound). Playback Mode For playing the recorded files When the device is turned on, by default it will be in Video mode. - Page 13 Contact Us Via: support@dsoon-tech.com Please press the “Mode” button (9) to switch to Photo mode. Please contact us if you have any questions...
-
Page 14: Focusing The Image
Contact Us Via: support@dsoon-tech.com View your subject via the LCD screen. Focusing the image On the left lens, marked “far” and “near”. If the observation distance is far, please rotate the lens to left. If the distance is near, please rotate the lens to right. Users can repeatedly adjust the optimal focal length according to the actual observation distance. -
Page 15: Turn On Ir
Contact Us Via: support@dsoon-tech.com appears on the LCD screen, the maximum support 4x zoom. Zoom Off Zoom On Turn on IR In photo/video mode, if you have to view the darkness environment, please short press IR UP button to activate the IR LEDs, the image will change to black and white. - Page 16 Contact Us Via: support@dsoon-tech.com IR LEDs have seven levels, short press IR UP button to up the level, short press IR DOWN button to down the level. (If the battery voltage is not enough, the IR LEDs level will down automatically. IR level can up to 7 level when the battery power is full.
- Page 17 Contact Us Via: support@dsoon-tech.com ＜25% IR Off IR On Please contact us if you have any questions...
-
Page 18: Shoot Video/Photo
Contact Us Via: support@dsoon-tech.com Shoot video/photo Turn on the device, if not in video/photo mode, please press MODE button to switch to video/photo mode. The lens is aimed at the target and observed through the screen. Press the SHOT button to start recording/taking, and the recording duration will be displayed on the screen. - Page 19 Contact Us Via: support@dsoon-tech.com select the item you want to change. Menu Function Photo Set the photo resolution. Resolution Options:[1M 1280x960]/[VGA 640x480] Set the video resolution. Video Size Options:[960 1280x960]/[640 640x480]. Night vision Choose the night vision sensitivity. Sensitivity Options:[Low]/[Middle]/[High].
- Page 20 Contact Us Via: support@dsoon-tech.com Options:[50Hz]/[60Hz]. Date&Time Set the date and time of device. Add the date stamp on the photo or video files. Date Stamp Options:[Off]/[Date]/[Date&Time]. Set OSD (on-screen) language. Options:[English] / [Simplified Chinese / [Traditional Chinese] / [French] / [Dutch] /...
-
Page 21: Playback Video/Photo
Contact Us Via: support@dsoon-tech.com Restoring factory setting will delete all Reset previous user settings. device Options:[Yes]/[No] User can see the firmware version FW Version information. Playback Watching Stored Videos and Photos in the photo mode: Please contact us if you have any questions... -
Page 22: Delete& Lock
Contact Us Via: support@dsoon-tech.com press MODE button to select the Playback mode. In playback mode, press the up or down button to turn pages forward and backward, the playback order is the shooting order. 10) Delete & Lock Menu Function... -
Page 23: Unclear Image Reasons
Contact Us Via: support@dsoon-tech.com Delete the current one Delete stored videos and Delete file or delete all files in photos in playback mode, memory card. press MENU button to enter the “delete” option, select the Options: [One]/[All]. delete option, and then select the content to be deleted. - Page 24 Contact Us Via: support@dsoon-tech.com If at day, make sure the IR is off (if IR is on, screen will turn from colored to black and white ). If at night, make sure you have turned on the IR, press IR up(3) (if IR is on, screen is black and white).
- Page 25 Contact Us Via: support@dsoon-tech.com Please do not use it through windows. Please use the device in the correct direction as shown in the figure. Please contact us if you have any questions...
-
Page 26: Download Files To Pc
Contact Us Via: support@dsoon-tech.com ◆ Download files to PC There are two ways to download files from the device to a computer: By inserting the memory card into a card reader. By connecting the device to a computer using the supplied USB cable. -
Page 27: Maintenance
Contact Us Via: support@dsoon-tech.com the computer's hard disk. Connecting the Device to a PC through the USB Cable Turn on the night vision. Connect it to a computer through the supplied USB cable. When connecting to the computer, will appear “MSDC”... -
Page 28: Warranty
Contact Us Via: support@dsoon-tech.com supply (remove batteries)! Only use dry cloth to clean the exterior of the device. To avoid damaging the electronics, do not use any cleaning fluid. Clean the eyepieces and/or lenses only with a soft, lint-free cloth, (e.g. Microfiber cloth). -
Page 29: Faq
Contact Us Via: support@dsoon-tech.com Please don't hesitate to contact us with any questions and problems. You can contact us via: support@dsoon-tech.com Email: ◆ FAQ How many batteries are 6AA alkaline batteries required? And how long 4H with IR on/11H with IR off... - Page 30 Contact Us Via: support@dsoon-tech.com What's included in the 32G TF Card x1 package? User Manual x1 Backpack x1 Anti Static Wiping Cloth x1 Paper Card for Screen x1 What's the zoom factor? 3x Lens Magnification/4x Digital Zoom What's the size of the 2.31”...
- Page 31 Contact Us Via: support@dsoon-tech.com Please contact us if you have any questions...
- Page 32 Contact Us Via: support@dsoon-tech.com Please contact us if you have any questions...
