- Page 1 Smooth Series Knee Walker R250, R270, R290 ATTENTION Before using this Medical Device read this manual. If you are unable to understand, contact your equipment provider for technical support before attempting to use this product. © TUFFCARE, INC. ALL RIGHTS RESERVED...
-
Page 2: Table Of Contents
8 - 12 R290 13 - 16 Adjustment 17 - 19 Tuffcare’s Smooth series knee walker is Operation designed for ankle or lower leg individuals recovering from a broken foot, broken ankle, Maintenance broken leg, foot surgery, or ankle surgery. More... -
Page 3: Warning
WHEELS • Apply the brakes while walking to maintain speed and control. When kneeling or sitting on the Smooth Knee Walker: R250 Components • Do not kneel or sit on the walker without applying the parking brakes. • Do not lean over your knee walker for any reason. Check before use that the product is stable, rigid and that all rivets ②... - Page 4 R250 Assembly Insert the front wheel assembly into the bottom tube of the steering column. Align hole in wheel assembly with the post. Insert the pentagram knob screw through the holes tighten pentagram knob by turning it clockwise to secure.
-
Page 5: R270
BRAKE LOCK HANDGRIP BRAKE HANDLE STEERING SHAFT PENTAGRAM KNOB BASKET GEL SEAT STEERING COLUMN LOCK DRUM BRAKE Insert the steering handle into the steering column, making sure not to twist the brake cables. Align holes in tiller, then insert the pentagram knob screw through the steering tiller. Align holes in tiller to desired height tighten with pentagram knob screw and secure. - Page 6 R270 Assembly Insert the front wheel assembly into the bottom tube of the steering column. Align hole in wheel assembly with the post. Insert the pentagram knob screw through the holes tighten pentagram knob by turning it clockwise to secure. Raise the steering column to it’s upright position and follow Remove the 11 major components from packaging.
- Page 7 Slide the calf pad onto the side where the injury leg is located. Align the hole in footrest post with the oval space Attach basket by lining up the bracket on basket with the at the back part of the calf pad. Insert the large pentagram screws on the knee walker.
-
Page 8: R290
R290 Assembly BRAKE LOCK HANDGRIP STEERING SHAFT BRAKE HANDLE PENTAGRAM KNOB KNEE PAD STEERING COLUMN LOCK DRUM BRAKE FRAME 10” PNEUMATIC FOLDING CASTER HINGE WHEELS R290 Components ① ③ ② ④ Remove the 4 major components from packaging. 1. main frame 2. - Page 9 Raise the steering column to it’s upright position and follow Insert the steering handle into the steering column, making steps (1) to (6) in page 17 to lock steering column. The sure not to twist the brake cables. Align holes in tiller, then locking mechanism at the base of the steering column has insert the pentagram knob screw through the steering tiller.
- Page 10 To Raise the Steering Column - Push the steering column upward until it is in the full upright position(1,2). Push the lever to the left(3) and downward at the same time to disengage the pin(4) And push the steering column upward until it is in the full upright position.
-
Page 11: Operation
The handlebars should be set at a comfortable distance in front of your body, normally about waist height. You should not be hunched over the unit, but in your normal, upright posture. R250 R270 R290 3. Before mounting the knee walker, ensure the hand... -
Page 12: Maintenance
DO NOT use the knee walker. Tel 800-367-6160 Use soapy water and a soft cloth to East Coast Distribution clean the surface of the walker. Wipe off Tel 800-548-6596 any moisture after cleaning. Using abra- WWW.TUFFCARE.COM sive clothes or other products can cause grates.
