OPERATING INSTRUCTIONS KM 3100 SE
STANDARD ACCESSORIES
TECHNICAL DATA
Standard version and extended version
Power requirement: 20 Ampere/2,25 kW, fuse protection with circuit breaker B16A
WORKING WITH THE MACHINE
Changing the direction of spindle rotation
Movable Control Box
Fine- Adjusting of headstock to "0" Position
Indexing
WORKING WITH CHUCKS
Outrigger for turning with swivelled headstock
SAFETY ADVICES AND REGULATIONS
ACCESSORIES AND OPTIONS
Copying Units, Laterial Turning Device, Ball Bearing Device
CE CONFORMITE
PAGE 2
PAGE 2
PAGE 2
PAGE 3
PAGE 3
PAGE 4
PAGE 5
PAGE 6
PAGE 6
PAGE 6
PAGE 6
PAGE 8
Advertisement
Table of Contents
Related Manuals for steinert KM 3100 SE
Summary of Contents for steinert KM 3100 SE
-
Page 1: Table Of Contents
OPERATING INSTRUCTIONS KM 3100 SE STANDARD ACCESSORIES PAGE 2 TECHNICAL DATA PAGE 2 Liability SETTING UP THE MACHINE PAGE 2 Lifting and Moving Standard version and extended version PAGE 3 ELECTRIC CONNECTION Power requirement: 20 Ampere/2,25 kW, fuse protection with circuit breaker B16A... - Page 2 STANDARD FITTINGS 4-prong-mandrel MT2 D=25 mm for spindle/headstock 4-prong mandrel MT 2 D=35 mm For spindle/headstock Live centre MT2/60 ° For tailstock quill Live centre MT2/with pressring D=20x26 mm For tailstock quill Indexing Pin Mounted fix at spindle nose never use the indexing pin for locking the spindle! Tool Rest bottom part Tool Rest 350 mm Toolbox with rubber mat...
-
Page 3: Liability
LIABILITY It is not permitted to make alterations or additions to the construction of the machinery supplied, to parts of the machinery supplied or to accessories. Any warranty and liability claims become void in such case. SETTING UP THE MACHINE The anti-rust protection must be removed from the bright machine parts before first use. -
Page 4: Emergency Off Button
CHANGING TURNING DIRECTION = ROTATION OF SPINDLE to righthanded rotation, clockwise correct turning direction is anticlockwise, lefthanded rotation the flip switch/or selector for forward/reverse switch is integrated at the movable box. For adjusted turning direction watch the sticker on the headstock when changing the turning direction the inverter will automatically slow down the speed: spindle starts slow in opposite direction, speed increases again as adjusted before Caution to meet safety regulations... - Page 5 STOP ADJUSTMENT FOR HEADSTOCK It prevents the headstock moving lengthways if the tailstock is used as counter pressure for big and heavy parts Caution: If headstock shall be moved or swivelled the clamping plate with hexagon screw must be removed ! FINE ADJUSTMENT OF HEADSTOCK FOR “ZERO-POSITION”...
- Page 6 Push the sliding stop in direction to the lefthand side (lefthand = seen from frontside of spindle) at least tighten the headstock clamping lever and screw in the adjustment bolt again The tips are now correctly in alignment a requirement for exact boring work or turning of writing utensils CAUTION: before you move or swivel the headstock The sliding stop must be pushed upwards until its end stop We also recommend to loosen lever of spindle headstock before...
-
Page 7: Operating Chucks, Prong Mandrel, Live Centre
OPERATING CHUCKS, PRONG MANDREL AND LIVE CENTRE The chucks are mounted on the external thread M 33 of the spindle, which is having a centering collar Switch off spindle motor lock spindle with fixing pin (below of spindle nose) ... -
Page 8: Maintencance
Indexing pin, excenter shaft of tool rest, quill and spindle should be oiled between 4-6 month to ensure true running and prevend seizing up. ACCESSORIES, ATTACHMENTS, OPTIONS, COPYING UNITS We refer to our Accessory Catalogue and our web-page www.drechslershop.de Drechselzentrum Erzgebirge - steinert® Heuweg 4 09526 Olbernhau Tel./Phone: +49 (0)37360-6693-0... - Page 9 Level of sound pressure according to 86/188/EED & 89/392 EEC, measured according to EN 50144: Lpa sound pressure 66 dB (A) Lwa acoustic power 81 dB (A) The maximum peripheral speed of the Lathe may not exceed 30 m/s. Drechselzentrum Erzgebirge - steinert® Heuweg 4 09526 Olbernhau Deutschland Roland Steinert/ Inhaber...
- Page 10 EN 13849-1 EN 60 204 T 1 EN 1088 Diese Erklärung wird verantwortlich für DRECHSELZENTRUM ERZGEBIRGE - steinert® abgegeben durch: This declaration is made for and on behalf of DRECHSELZENTRUM ERZGEBIRGE - steinert® by: Roland Steinert (Inhaber / Owner) Unterschrift:_______________________________________...
