Parts list

Profile kit
A1
Profile 40mm slot 8 (Black, 40x40L) - 500mm
A2
Profile 40mm slot 8 (Black, 40x80L) - 195mm
A3
Profile 40mm slot 8 (Black, 40x80L) - 1350mm
A4
Profile 40mm slot 8 (Black, 40x80L) - 330mm
A5
Profile 40mm slot 8 (Black, 40x80L) - 500mm
A6
Profile 40mm slot 8 (Black, 40x80L) - 540mm
Hardware kit
B1
GT1 EVO pedal deck
B2
GT1 EVO wheeldeck pivot plate (LEFT)
B3
GT1 EVO wheeldeck pivot plate (RIGHT)
B4
GT1 EVO wheeldeck plate
B5
End cap profile (40x40L)
B6
End cap profile (40x80L)
B7
Rubber feet
B8
Slot 8 nut (M6)
B9
Slot 8 nut (M8)
B10 Washer (Black steel, M8, Plain black)
B11
Bolt - DIN 912 (Galvanised, 16mm, M8)
B12 Bolt - DIN 912 (Black steel, 12mm, M8)
B13 Bolt - DIN 912 (Galvanised, 20mm, M6)
B14 Nut (M8, DIN 985 locknut, Galvanised)
B15 Nut (M6, DIN 985 locknut, Galvanised)
B16 Nut (M5, DIN 985 locknut, Galvanised)
B17
Bolt - DIN 912 (Black steel, 20mm, M8)
B18 Bolt - DIN 912 (Black steel, 16mm, M8)
B19 Bolt - DIN 912 (Black steel, 20mm, M6)
B20 Bolt - DIN 912 (Black steel, 16mm, M6)
B21 Bolt - DIN 912 (Black steel, 25mm, M5)
B22 Corner Bracket + cover cap
Part name
2 Units
2 Units
2 Units
1 Units
3 Units
2 Units
Qty UoM
1 Units
1 Units
1 Units
1 Units
4 Units
9 Units
4 Units
10 Units
70 Units
12 Units
60 Units
4 Units
8 Units
8 Units
12 Units
12 Units
8 Units
12 Units
12 Units
10 Units
12 Units
28 Units
Note
