Parts list

BOX A
Base profiles
Part No.
A1 Profile 40mm slot 8 (Black, 40x80L) - 1195mm
A2 Profile 40mm slot 8 (Black, 40x80L) - 420mm
A3 Profile 40mm slot 8 (Black, 40x80) - 500mm
BOX B
Hardware kit
Part No.
B1 Corner bracket 4040E + Cover cap
B2 End cap profile (40x80L)
B3 Rubber feet
B4 Handle M8x20
B5 Plastic sleeve black (10mm)
B6 Bolt - DIN 912 (Black steel, 20mm, M8)
B7 Bolt - DIN 912 (Black steel, 25mm, M8)
B8 Bolt - DIN 912 (Black steel, 16mm, M6)
B9 Bolt - DIN 912 (Black steel, 16mm, M8)
B10 Bolt - DIN 912 (Black steel, 20mm, M6)
B11 Bolt - DIN 7991 (Black steel, 20mm, M8)
B12 Nut (M8, DIN 985 locknut, Galvanised)
B13 Washer (Black steel, M8, Plain black)
B14 Slot 8 nut (M8)
B15 Slot 8 nut (M6)
B16 Plastic sleeve black (10mm, M6)
B17 Bolt - DIN 7991 (Black steel, 20mm, M6)
B18 TR1/GT2 pedal deck triangle (set of 2)
B19 TR1/GT2 45 degree wheeldeck sidemount (set of 2)
B20 TR1/GT2 brace
Front mount set
Part No.
B21 GT2 Front mount set (Front + Left + Right plate)
B22 Corner bracket 4040E + Cover cap
B23 Bolt - DIN 912 (Black steel, 20mm, M6)
B24 Bolt - DIN 912 (Black steel, 20mm, M8)
B25 Bolt - DIN 912 (Black steel, 40mm, M8)
B26 Bolt - DIN 7991 (Black steel, 25mm, M8)
B27 Bolt - DIN 7991 (Black steel, 30mm, M8)
B28 Nut (M8, DIN 985 locknut, Galvanised)
B29 Spacer - male / female (10mm, M6)
B30 Washer (Black steel, M8, Plain black)
B31 Slot 8 nut (M8)
BOX C
Pedal frame
Part No.
C1 Profile 40mm slot 8 (Black, 40x40L) - 420mm (M8 thread)
C2 Profile 40mm slot 8 (Black, 40x40L) 320mm
C3 Profile 40mm slot 8 (Black, 40x80L) - 420mm
C4 Corner bracket 4040E + Cover cap
C5 End cap profile (40x40L)
C6 Joint 40
C7 Bolt - DIN 912 (Black steel, 16mm, M8)
C8 Bolt - DIN 912 (Black steel, 20mm, M8)
C9 Bolt - DIN 912 (Black steel, 16mm, M5)
C10 Bolt - DIN 912 (Black steel, 16mm, M6)
C11 Washer (Black steel, M8, Plain black)
C12 Slot 8 nut (M8)
C13 Slot 8 nut (M6)
C14 Slot 8 nut (M5)
Part name
Part name
Part name
Part name
QTY UoM
2 Units
2 Units
2 Units
QTY UoM
8 Units
8 Units
4 Units
2 Units
2 Units
10 Units
4 Units
4 Units
20 Units
4 Units
30 Units
8 Units
10 Units
50 Units
20 Units
4 Units
4 Units
1 Units
1 Units
1 Units
QTY UoM
1 Units
4 Units
4 Units
6 Units
4 Units
4 Units
4 Units
12 Units
4 Units
12 Units
4 Units
QTY UoM
2 Units
3 Units
1 Units
10 Units
2 Units
2 Units
24 Units
2 Units
12 Units
12 Units
28 Units
34 Units
12 Units
12 Units
Note
Note
Note
Note
