Summary of Contents for Bestisan Pillar SG02
- Page 1 BESTISAN Best Artisan & Better Than Most Pillar Model: SG02 2.0 Channels 32 Inches Version 1.0 USER MANUAL...
-
Page 3: Checking The Components
01 Checking the Components Soundbar Remote control User’s guide Insert 2pc of AAA batteries before use Digital Optical cable 3.5mm to 3.5mm audio cable Power adapter Wall mount brackets Mount screws Wall mount template... -
Page 4: Product Overview
02 Product Overview Front Panel / Top Side Panel of the Soundbar LED indicator, display di erent color and current mode. Bluetooth Optical Coaxial Turn the power on or press and hold to power o . Select the source input mode; Press and hold to reset treble and bass to factory settings. Press to adjust volume up and down, the LED indicator flashes until the volume to the MAX or MIN. - Page 5 Bottom Panel of the Soundbar AUX IN OPTICAL COAX IN SUB OUT DC IN (Power Supply In), connect the AC/DC power adapter. USB, connect a USB device here to play music files on the USB device through the Soundbar. AUX(3.5mm), connect to the Analog output of an external device. Digital Audio In (optical), connect to the digital (optical) output of an external device.
-
Page 6: Connecting Electrical Power
03 Connecting Electrical Power Bottom Panel of the Soundbar AUX IN OPTICAL COAX IN SUB OUT Using the power adapter to connect the unit to electrical outlet in the figure Make sure to Place the AC/DC adapter flat on a table or the floor. If you place the AC/DC adapter so that it is hanging with the AC cord input facing upwards, water or other foreign substances could enter the adapter and cause the adapter to malfunction. -
Page 7: Connecting With A Tv
04 Connecting with a TV Connecting using an Optical cable Bottom Panel of the Soundbar OPTICAL OUT AUX IN OPTICAL COAX IN SUB OUT Optical digital cable (supplied) White Optical color LED 1. Connect the DIGITAL AUDIO IN(OPTICAL) jack on the Soundbar to the OPTICAL OUT jack of the TV with a digital optical cable. - Page 8 05 Setting “PCM” on your TV When all cables are connected properly, and LED indicator lights properly(Optical connection), if there is no sound from tv or Soundbar, please setting your tv as below: 1. Press "Menu" on the tv’s remote control. 2.
- Page 9 06 Connect an external speaker (subwoofer) Bottom Panel of the Soundbar Back Panel of the Subwoofer Outlet AUX IN OPTICAL COAX IN SUB OUT audio cable (excluded) subwoofer sold separately.
-
Page 10: Connecting An External Device
07 Connecting an External Device Bottom Panel of the Soundbar BD / DVD / Set-top box / Game console AUX IN OPTICAL COAX IN SUB OUT Optical digital cable OPTICAL OUT 3.5mm to 3.5mm audio cable Connect DIGITAL AUDIO (OPTICAL) on the Soundbar to the OPTICAL OUT jack of the Source Device using a digital optical cable. -
Page 11: Connecting A Usb
08 Connecting a USB Bottom Panel of the Soundbar AUX IN OPTICAL COAX IN SUB OUT USB Device Purple color LED 1. Connect your USB device to the USB jack on the Soundbar. 2. Select “PURPLE” led indicator by pressing the “USB” button on the remote. 3. -
Page 12: Connecting A Bluetooth Device
1. Press the “BT” button on the remote, the LED indicator blinks blue. 2. Turn on Bluetooth on the Bluetooth device. (see the device’s manual for more information) 3. Select “Bestisan SG02” from the list, connect it. When your Bluetooth device is connected, the LED indicator blinks blue slowly. - Page 13 Additional Bluetooth information 1. If you hear any break-up while streaming music from your device, move closer to your Soundbar. 2. Bluetooth signal has a range of up to 30 feet if there are no solid obstructions between your Soundbar and source device. 3.
-
Page 14: Know Your Remote
10 Know Your Remote Power the remote by inserting 2 pcs of AAA batteries Power Button Mute / Unmute Volume up Previous track Next track Volume down Coaxial mode Optical mode Bluetooth mode (press and hold to disconnect BT) USB mode RCA mode Recommended audio mode-MOIVE Recommended audio mode-DIALOG... -
Page 15: Installing The Wall Mount
11 Installing the Wall Mount 1. Insert the two wall-mount screws into the wall- 3. Remove the template, using an appropriately mount screw holes, and tighten them with a sized drill bit, drill a hole in the wall at each screwdriver. -
Page 16: Troubleshooting
12 Troubleshooting If you have a problem with your Sound Bar, there is quick simple solution, first make sure: The cables between Sound Bar and input devices are securely connected, the power adapter is also connected to a working power source. The adapter LED indicator is lighting, and the LED indicator is lighting in the middle of Sound bar, No sound or crackling noise Check if all cables are connected properly. - Page 17 Be sure that there are no solid obstructions between the Sound Bar and source device.(within 30 feet) Reboot the Bluetooth and connect again. Hear echo when watching TV Setting your TV audio to External Speaker. Mute the TV speaker. Have other questions? service@bestisan.com Please contact for assistance.
- Page 18 BESTISAN Best Artisan & Better Than Most Thanks for reading! Best Artisan C Corp. Version 1.0 801 DUPONT AVE SUITE F & G, ONTARIO, CA, 91761. service@bestisan.com...
