Chapter 1 Introduction Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features • 23.8″ wide format LCD (EV2450) • 24.1″ wide format LCD (EV2455) • Supports a resolution of 1920 × 1080 (EV2450) •...
Page 8
This software can be downloaded from our web site (http://www.eizoglobal.com). • Supports the “EIZO Monitor Configurator” software for creating monitor configuration files When installing multiple units of this monitor, this software allows users to apply a single configuration file to all monitors at the same time. This increases the efficiency of monitor installation work by eliminating the need for configuring each monitor individually.
Chapter 1 Introduction 1-2. Controls and Functions ● Front Setting menu 1. EcoView Sense sensor Detects user movement in front of the monitor (EcoView Sense function (page 19)). 2. Ambient light sensor Detects ambient brightness (Auto EcoView function (page 18)). 3.
Chapter 1 Introduction ● Rear 6. Main power switch Turns the main power on or off. 7. Power connector Connects the power cord. 8. Input signal connectors The following connectors are available on the monitor rear in order of left to right. D-Sub mini 15-pin connector DisplayPort connector HDMI connector...
Chapter 1 Introduction 1-4. Setting the Resolution If the resolution is incorrect after connecting the monitor to a PC or if you want to change the resolution, follow the procedure below. ● Windows 8.1 / Windows 8 / Windows 7 1.
Chapter 2 Basic Adjustment/Setting Chapter 2 Basic Adjustment/Setting This monitor enables users to change the brightness according to personal preference or to suit the usage environment and reduce power consumption to conserve energy. This chapter describes the basic functions that can be adjusted and set using the switches on the front of the monitor. For advanced adjustment and setting procedures using the Setting menu, see “Chapter 3 Advanced Adjustment/Setting”...
Chapter 2 Basic Adjustment/Setting 2-2. Switching Input Signals When a monitor has multiple signal inputs, the signal to display on-screen can be changed. - 15 -...
Chapter 2 Basic Adjustment/Setting 2-3. Switching Display Modes (Color Modes) This product is preinstalled with color modes for various display purposes. Switch the mode according to the purpose and content for display. This allows the monitor to display images in a manner appropriate to the display content. ●...
Chapter 2 Basic Adjustment/Setting 2-4. Conserving Energy This monitor is equipped with EcoView functions to enable users to conserve energy. Use this function to curtail unnecessary power consumption and save on electricity expenses. Saving power also reduces carbon dioxide emissions. Level of power saving Note •...
Page 18
Chapter 2 Basic Adjustment/Setting Function Setting Range Description Note Auto EcoView The ambient light sensor on the front of the monitor • Be careful not to block the ambient light sensor detects the ambient brightness to automatically on the lower side of the monitor when using the adjust the screen brightness to a comfortable Auto EcoView function.
Page 19
Chapter 2 Basic Adjustment/Setting Function Setting Range Description Note EcoView Sense When set to “On”, the sensor on the front of the • At the time of shifting to power saving mode, monitor detects user movement. When the user a message that indicates the transition is moves away from the monitor, it automatically displayed.
Chapter 2 Basic Adjustment/Setting 2-5. Adjusting Brightness The brightness of the screen can be adjusted to suit the installation environment or personal preference. The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel). Setting Range 0 to 100 Note...
Chapter 2 Basic Adjustment/Setting 2-6. Adjusting Volume The volume of the speakers and headphones can be set individually. Setting Range 0 to 30 - 21 -...
Chapter 3 Advanced Adjustment/Setting Chapter 3 Advanced Adjustment/Setting This chapter describes the advanced monitor adjustment and setting procedures using the Setting menu. For basic functions, see “Chapter 2 Basic Adjustment/Setting” (page 14). 3-1. Basic Operation of the Setting menu Menu display 2.
Chapter 3 Advanced Adjustment/Setting 3-2. Setting Menu Functions ● Color Adjustment The color mode setting status can be adjusted according to personal preference. Attention • It takes about 30 minutes for the performance of electrical parts to stabilize. Please wait 30 minutes or more after power to the monitor has been turned on before adjusting the monitor.
Page 24
Chapter 3 Advanced Adjustment/Setting Color Mode (Functions that can be adjusted differ depending on the color mode.) Setting Function Description Note √: Adjustable -: Not adjustable Range User1 sRGB Paper Movie DICOM User2 Contrast √ √ 0 to 100 The brightness of the screen is adjusted by •...
Page 25
Chapter 3 Advanced Adjustment/Setting Color Mode (Functions that can be adjusted differ depending on the color mode.) Setting Function Description Note √: Adjustable -: Not adjustable Range User1 sRGB Paper Movie DICOM User2 Advanced Overdrive √ Enhanced This function allows you to set the overdrive Settings Standard intensity based on the use of the monitor.
Chapter 3 Advanced Adjustment/Setting ● Signal Settings Set the method for outputting the signal input from the PC to the monitor. Input Signal (The setting range of each function differs depending on the input signal.) √: Settable -: Not settable Function Setting Range Description...
Page 27
Chapter 3 Advanced Adjustment/Setting Input Signal (The setting range of each function differs depending on the input signal.) √: Settable -: Not settable Function Setting Range Description Note HDMI DisplayPort D-Sub Video signal signal Sharpness √ √ √ √ √ 1 to 5 When a low-resolution image is displayed in “Full •...
Page 28
Chapter 3 Advanced Adjustment/Setting Input Signal (The setting range of each function differs depending on the input signal.) √: Settable -: Not settable Function Setting Range Description Note HDMI DisplayPort D-Sub Video signal signal Analog Auto √ Screen flickering, display position, and size can be •...
Page 29
Chapter 3 Advanced Adjustment/Setting Input Signal (The setting range of each function differs depending on the input signal.) √: Settable -: Not settable Function Setting Range Description Note HDMI DisplayPort D-Sub Video signal signal Clock √ Flickering of vertical lines on the screen or part of the •...
Page 30
Chapter 3 Advanced Adjustment/Setting Input Signal (The setting range of each function differs depending on the input signal.) √: Settable -: Not settable Function Setting Range Description Note HDMI DisplayPort D-Sub Video signal signal Sound Source √ Stereo Mini Jack The audio source can be changed when receiving •...
Chapter 3 Advanced Adjustment/Setting ● Preference Settings The monitor’s settings can be configured to suit the usage environment or personal preference. Function Setting Range Description Note Menu Rotation 0˚ Change the orientation of the Setting menu when using the • Make sure that the cables are correctly connected. 90˚...
Page 32
Chapter 3 Advanced Adjustment/Setting Function Setting Range Description Note Power Save The monitor can be set to enter power saving mode according to • At the time of shifting to power saving mode, a the state of the PC. message that indicates the transition is displayed 5 The monitor changes to power saving mode about 15 seconds seconds in advance.
Chapter 3 Advanced Adjustment/Setting ● Language The display language for menus and messages can be selected. Setting Range English, Deutsch, Français, Español, Italiano, Svenska, Japanese, Simplified Chinese, Traditional Chinese Attention • The display language of the “Administrator Settings” menu cannot be changed. ●...
Chapter 4 Administrator Settings Chapter 4 Administrator Settings This chapter describes how to configure monitor operation using the “Administrator Settings” menu. This menu is for administrators. Configuration on this menu is not required for normal monitor use. 4-1. Basic Operation of the “Administrator Settings” Menu Menu display Setting 1.
Chapter 4 Administrator Settings 4-2. Functions of the “Administrator Settings” Menu Function Setting Range Description Note Auto Input Detection This monitor recognizes the connector through which PC signals • When this function is set to “On”, the monitor only are input and displays images on the screen accordingly. When a enters power saving mode after all connected PCs PC is turned off or enters power saving mode, any other available have entered power saving mode or have been...
Page 36
On-Screen Logo When the monitor is turned on, the EIZO logo appears on the screen. When this function is set to “Off”, the EIZO logo does not appear. Key Lock In order to prevent changes to settings, the operation switches on •...
Chapter 5 Troubleshooting Chapter 5 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local EIZO representative. 5-1. No picture Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly.
Page 38
Chapter 5 Troubleshooting Problem Possible cause and remedy 2. The message below appears. This message appears when the signal is not input correctly even though the monitor is functioning properly. • The message shows that the input signal is out •...
“Color Adjustment” (page 23)). (The LCD monitor backlight has a limited life span. When the screen becomes dark or begins to flicker, contact your local EIZO representative.) • If the screen is too bright, try changing the Auto EcoView setting to “On”. The monitor detects the ambient brightness to adjust the screen brightness automatically (see “Auto EcoView”...
Chapter 5 Troubleshooting Problem Possible cause and remedy 5. Green / red / blue / white dots or dark dots • This is due to LCD panel characteristics and not a malfunction. remain on the screen. 6. Interference patterns or pressure marks •...
• Try changing to a different USB port. If the PC or peripheral devices work correctly by changing the USB port, contact your local EIZO representative. (Refer to the manual of the PC for details.) • Reboot the PC.
Chapter 6 Reference Chapter 6 Reference 6-1. Attaching the Optional Arm An optional arm (or an optional stand) can be attached by removing the stand section. Please refer to our web site for the corresponding optional arm (or optional stand). http://www.eizoglobal.com Attention •...
Chapter 6 Reference Attachment procedure Lay the LCD monitor on a soft cloth spread over a stable and flat surface with the panel surface facing down. Remove the stand. Prepare a screwdriver. Use the screwdriver to loosen the screws (four) that secure the unit to the stand. Attach the arm or stand to the monitor. Secure the monitor to the arm or stand using the screws specified in the User’s Manual of the arm or stand.
Page 44
Chapter 6 Reference Turn the stand base in the counterclockwise direction to detach it. Note • Reattach the fixing screw onto the stand base for when the stand base is used again. Attachment procedure The once removed the stand base can be attached to the monitor again with the following procedures. Check that the fixing screw is firmly attached to the bottom of the stand base.
Page 45
Chapter 6 Reference Insert the stand brace into the stand base. Stand brace Stand base - 45 -...
Page 46
Chapter 6 Reference Turn the stand brace in the clockwise direction until it clicks. - 46 -...
Chapter 6 Reference 6-3. Attaching/Detaching the Cable Holder A cable holder is supplied with this product. Use the cable holder to organize the cables connected to the monitor. Attachment procedure Pass the cables through the cable holder. Close the opening in the cable holder. While holding the cable holder closed, attach it onto the stand.
Page 48
Chapter 6 Reference Note • The cable holder can be inserted either perpendicular or parallel to the stand. Change the direction of the cable holder according to the condition of the cables. Detachment procedure Close the opening in the cable holder. While holding the cable holder closed, remove it from the stand.
Chapter 6 Reference 6-4. Connecting Multiple PCs This product can be connected to multiple PCs and allows you to switch between the connections for display. Connection Note examples • The input signal changes each time the D-Sub DisplayPort DVI-D HDMI connector connector connector...
• A PC equipped with a USB port • Windows 8.1 / Windows 8 / Windows 7 / Windows Vista, Mac OS X 10.2 or later, Mac OS 9.2.2 • EIZO USB cable (UU200SS (USB 3.0)) Attention • This monitor may not work depending on the PC, OS, or peripheral devices to be used. For USB compatibility of peripheral devices, contact their manufacturers.
Chapter 6 Reference 6-6. Specifications EV2450 LCD Panel Type IPS (Anti-Glare) Backlight Size 60 cm (23.8 inch) (60.4 cm diagonal) Native Resolution 1920 dots × 1080 lines Display Size (H × V) 527.04 mm × 296.46 mm Pixel Pitch 0.2745 mm Display Colors 8-bit colors: 16.77 million colors...
Page 52
Chapter 6 Reference Power Input 100 - 120 VAC ±10 %, 50 / 60 Hz 0.80 A 200 - 240 VAC ±10 %, 50 / 60 Hz 0.50 A Maximum Power Consumption 47 W or less Power Save Mode 0.3 W or less (no USB device connected, default settings) Standby Mode 0.3 W or less (no USB device connected, default settings) Physical...
Page 53
Chapter 6 Reference EV2455 LCD Panel Type IPS (Anti-Glare) Backlight Size 61 cm (24.1 inch) (61.1 cm diagonal) Native Resolution 1920 dots × 1200 lines Display Size (H × V) 518.4 mm × 324.0 mm Pixel Pitch 0.27 mm Display Colors 8-bit colors: 16.77 million colors Viewing Angle (H / V, typical)
Page 54
Chapter 6 Reference Power Input 100 - 120 VAC ±10 %, 50 / 60 Hz 0.85 A 200 - 240 VAC ±10 %, 50 / 60 Hz 0.55 A Maximum Power Consumption 49 W or less Power Save Mode 0.3 W or less (no USB device connected, default settings) Standby Mode 0.3 W or less (no USB device connected, default settings) Physical...
HDMI HPD Control USB Power Save On-Screen Logo Key Lock Compatibility Mode ● Accessories Signal cable • MD-C87 (D-Sub-D-Sub) • FD-C39 (DVI-DVI) Cleaning Kit EIZO “ScreenCleaner” For the latest information about accessories, refer to our web site. http://www.eizoglobal.com - 57 -...
Chapter 6 Reference 6-7. Preset Timings The following table lists the factory preset analog signal timings: Attention • The display position may deviate depending on the connected PC, and may require screen adjustment using the Setting menu. • If a signal other than those listed in the table is input, adjust the screen using the Setting menu. However, screen display may still be incorrect even after adjustment. •...
Chapter 7 Glossary Chapter 7 Glossary Clock The analog signal input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog signal is converted to a digital signal for image display. This is called clock adjustment. If the clock pulse is not set correctly, some vertical bars appear on the screen.
Page 61
Chapter 7 Glossary Gamma Generally, the monitor brightness varies nonlinearly with the input signal level, which is called “Gamma Characteristic”. A small gamma value produces a low-contrast image, while a large gamma value produces a highcontrast image. HDCP (High-bandwidth Digital Content Protection) Digital signal coding system developed to copy-protect the digital contents, such as video, music, etc.
Page 62
Chapter 7 Glossary Resolution The LCD panel consists of numerous pixels of specified size, which are illuminated to form images. This monitor consists of horizontal 1920 pixels and 1080 vertical pixels (EV2450), or horizontal 1920 pixels and 1200 vertical pixels (EV2455). At a resolution of 1920 × 1080 (EV2450) or 1920 × 1200 (EV2455), all pixels are illuminated as a full screen (1:1).
Appendix Appendix Trademark The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries. The DisplayPort Compliance Logo and VESA are registered trademarks of the Video Electronics Standards Association. Acrobat, Adobe, Adobe AIR, and Photoshop are registered trademarks of Adobe Systems Incorporated in the United States and other countries.
ENERGY STAR As an ENERGY STAR Partner, EIZO Corporation has determined that this product meets the ENERGY STAR guidelines for energy efficiency. This product has acquired the TCO standard that relates to the safety, ergonomics (EcoView Optimizer 2: Off, Temperature: Off), environment and so forth of office equipment.
Page 65
Appendix Congratulations! This product is TCO Certifi ed – for Sustainable IT TCO Certifi ed is an international third party sustainability certifi cation for IT products. TCO Certifi ed ensures that the manufacture, use and recycling of IT products refl ect environmental, social and economic responsibility. Every TCO Certifi ed product model is verifi ed by an accredited independent test laboratory.
Page 66
Appendix A detailed criteria set is available for download at www.tcodevelopment.com, where you can also fi nd a searchable database of all TCO Certifi ed IT products. TCO Development, the organization behind TCO Certifi ed, has been an international driver in the fi eld of Sustainable IT for 20 years. Criteria in TCO Certifi ed are developed in collaboration with scientists, experts, users and manufacturers.
Phone: (562) 431-5011 declare that the product Trade name: EIZO Model: FlexScan EV2450 / EV2455 is in conformity with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 68
Appendix Note Use the attached specifi ed cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord - Shielded Signal Cable (enclosed) Canadian Notice This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de le classe B est comforme à la norme NMB-003 du Canada. - 68 -...
Appendix Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden. Bei der Auswahl des Schwenkarms sind die nachstehenden Hinweise zu berücksichtigen: Der Standfuß...
Warranty. EIZO and Distributors will cease to hold or store any parts of the Product upon expiration of seven (7) years after the production of such parts is discontinued. In repairing the monitor, EIZO and Distributors will use renewal parts which comply with our QC standards.
Page 71
EIZO und die Vertriebe verpflichten sich, Ersatzteile für das Produkt über einen Zeitraum von sieben (7) Jahren nach Einstellung der Produktion der Ersatzteile zu lagern bzw. anzubieten. EIZO und seine Vertriebspartner verpfl ichten sich, bei einer etwaigen Reparatur des Monitors ausschließlich Produkte gemäß den EIZO-Qualitätssicherungsstandards zu verwenden.
Page 72
Garantie. EIZO et ses Distributeurs cesseront de tenir ou conserver en stock toute pièce de ce Produit après l’expiration de la période de sept (7) ans suivant l’arrêt de la production de telles pièces.
Page 73
(en lo sucesivo la “Garantía”), garantizan al comprador original (en lo sucesivo el “Comprador original”) que compró el producto especifi cado en este documento (en lo sucesivo el “Producto”) a EIZO o a sus Distribuidores, que EIZO y sus Distribuidores, a su propio criterio, repararán o sustituirán el Producto de forma gratuita si el Comprador original detecta dentro del periodo de la Garantía (indicado posteriormente) que el Producto no funciona correctamente o que se ha averiado durante el uso normal del mismo de...
Page 74
(a cui si farà riferimento da qui in poi con “Garanzia”) all’acquirente originale (a cui si farà riferimento da qui in poi con “Acquirente originale”) che ha acquistato il prodotto specifi cato in questo documento (a cui si farà riferimento da qui in poi con “Prodotto”) da EIZO o dai suoi Distributori, che EIZO e i distributori, a loro discrezione, ripareranno o sostituiranno il Prodotto senza addebito se l’Acquirente originale trova, entro il periodo della Garanzia (defi nito sotto), che il Prodotto malfunziona e si è...
Page 75
Produkten i relation till den Ursprunglige köparen eller tredje part. EIZO och Distributörer kommer att upphöra med lagerhållning av Produktens delar efter sju (7) år efter att produktionen av dessa delar upphört. Nät skärmen repareras använder EIZO och distributörer reservdelar som uppfyller våra kvalitetsstandarder.
Page 76
περιορισμένης εγγύησης (στο εξής «Εγγύηση»), στον αρχικό αγοραστή (στο εξής «Αρχικός Αγοραστής») ο οποίος αγόρασε το προϊόν που καθορίζεται στο παρόν έγγραφο (στο εξής «Προϊόν») από την EIZO ή τους Διανομείς, η οποία εξασφαλίζει ότι η EIZO και οι Διανομείς, σύμφωνα με τη διακριτή ευχέρειά τους, είτε θα επισκευάσουν είτε θα αντικαταστήσουν...
Page 77
Гарантия действительна только в странах или регионах, где расположены Дистрибуторы. Гарантия не ограничивает никакие законные права Первоначального покупателя. Несмотря на другие условия этой Гарантии EIZO и Дистрибуторы не несут никаких обязательств согласно этой Гарантии в любом из перечисленных ниже случаев: (а) Любые...
