Hanover Outdoor Furniture
If you have any problems with this product (missing or damaged parts, assembly issues, etc.),
PLEASE DO NOT RETURN TO THE RETAILER/STORE
Please call our Toll‐Free Customer Service Hotline at:
Between 9:00 AM and 5:00 PM Eastern Time, Monday through Friday
Or visit our website at:
To expedite any future warranty claims, please retain the Instruction Sheet, Warranty
Card and receipt for future use.
For additional on‐line support on assembly, troubleshooting and care & maintenance of your outdoor
furniture, please visit our website at: www.hanover‐products.com.
IMPORTANT
from where you purchased the product.
www.hanover‐products.com
1‐800‐416‐3511
6/1/2015 (a)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hanover Orleans ORL4PCTFPSW2-TAN
Summary of Contents for Hanover Orleans ORL4PCTFPSW2-TAN
- Page 1 Hanover Outdoor Furniture IMPORTANT If you have any problems with this product (missing or damaged parts, assembly issues, etc.), PLEASE DO NOT RETURN TO THE RETAILER/STORE from where you purchased the product. 1‐800‐416‐3511 Please call our Toll‐Free Customer Service Hotline at: Between 9:00 AM and 5:00 PM Eastern Time, Monday through Friday www.hanover‐products.com Or visit our website at: To expedite any future warranty claims, please retain the Instruction Sheet, Warranty Card and receipt for future use. For additional on‐line support on assembly, troubleshooting and care & maintenance of your outdoor furniture, please visit our website at: www.hanover‐products.com. 6/1/2015 (a) ...
- Page 2 ASSEMBLY INSTRUCTIONS Figure 1. Attach the seat frame to the back frame by using four 5/16"x40 mm bolts and washer as shown in Guide these bolts through the holes in the seat frame, into the fixed nuts already in place in the back frame. Do not over tighten Attach love seat arm by inserting two 5/16"x25...
-
Page 3: Parts List
PARTS IDENTIFICATION LIST * NOTE: PARTS SHOWN ON PARTS LIST ARE NOT TO SCALE ORDER PART # QTY PARTS LIST DESCRIPTION BACK FRAME SK0939 SK0940 SEAT FRAME LEFT ARM SK0941 SK0942 RIGHT ARM 5/16" X 25 MM BOLT HW0186 5/16" X 40 MM BOLT HW0275 Ø8.5 X 1.5 MM HW0005... - Page 4 ASSEMBLY INSTRUCTIONS Assemble furniture on a smooth, non-abrasive surface. Attach the back frame to right arm by using two 5/16"x40 mm bolts and washers as shown in . Guide the bolts through holes in back frame, into Fig.1 pre-drilled holes in the right arm Hand tighten only.
- Page 5 PARTS IDENTIFICATION LIST * NOTE: PARTS SHOWN ON PARTS LIST ARE NOT TO SCALE ORDER PART # QTY PARTS LIST DESCRIPTION SEAT FRAME SG0154 BACK FRAME SG0155 LEFT ARM SG0156 SG0157 RIGHT ARM GLIDER BASE W/ SG0158 GLIDER BRACKET SG0159 5/16"...
-
Page 6: Carbon Monoxide Hazard
ASSEMBLY INSTRUCTIONS ARL00200 CSA Model99010 Installer: Leave these instructions with consumer. Consumer: Keep these instructions for future reference DANGER WARNING: If you smell gas: Improper installation, adjustment alteration, 1. Shut off gas to the appliance. service or maintenance can cause injury or 2. - Page 7 PARTS IDENTIFICATION LIST PART DESCRIPTION PART# CONTROL KNOB FP1245 GAS VALVE FP0307 THERMOCOUPLE FP0004 LP REGULATOR 65-FP-0181 HOSE ELECTRODE 65-FP-0128 ORIFICE ELBOW FP0310 IGNITION FP0006 MODULE PROPANE ZCF0021 ORIFICE “AAA” HW0705 BATTERY(1.5V) LAVA ROCK SET FP0002 FOOTCAP FC0743 1/4" X 15 MM BOLT HW0034 1/4"...
- Page 8 TABLE RIM BACK PANEL LEFT SIDE PANEL RIGHT SIDE PANEL DOOR PANEL LP SUPPORT TILE-1 TILE-2 MIDDLE SUPPORT TABLE COVER BOTTOM/ TOP CONNECTOR...
-
Page 9: Installation
INSTALLATION 1. Identify parts packed in carton against the parts list. Remove all protective materials and set parts on a flat, non-abrasive surface. 2. Attach the back panel to side panels by using four 1/4"x40 mm bolts and washers as shown in Figure 2. - Page 10 5. Put the door onto the "L" connector (pre-assembled), guide the pin on the lower "L" connector into the hole under the door. Then guide the pin on the upper "L" connector into the hole in the upper portion of the door. Use a 1/4"x15 mm bolt and washer to secure the "L"...
- Page 11 8. Place gas tank onto the LP support as shown in Figure 8. Figure 8 9. Attach the metal ring (as shown in Figure 9) pre-fitted with gas hose which is connected to the table top, into the hole of the door panel, then use hex bolt driver to screw 1/4"x5mm nut, the gas tank has fixed as shown in Figure 10.
- Page 12 10. After making any necessary adjustments to the parts, use the hex bolt driver to tighten all bolts. Note: each bolt must be tightened a few revolutions at a time. Repeat until all bolts are tight. Do not over tighten. Over tightening may strip bolts. Cover all bolts with covers.
- Page 13 14. Open the tank valve. Apply a solution of soapy water to the tank-regulator connection and to the valve-hose connection to check for leaks as shown in Figure 14 If soap bubbles continue to form, the connection has a leak. If a leak is found, close the tank valve and tighten all connections.
-
Page 14: Lighting Instructions
LIGHTING INSTRUCTIONS Warning: If these instructions are not followed exactly, a fire or explosion may result in causing property damage, personal injury or loss of life. Make sure the control knob is in the "OFF" position. See Figure 16 Open the tank valve all the way. -
Page 15: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM CAUSE REMEDY Check that gas tank valve is open. Turn control knob to “ON” No Propane Gas at Burner and push control knob in. Make sure tank has propane gas. Check that AAA battery is installed with negative (-) end first and has a charge.
