4-
4.1 A
115 mm
Tile Wet Saw
Español página 17
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-877-876-7562, 8 a.m. - 5 p.m.,CST, Monday - Friday.
/
in.
1
2
Purchase Date
®
# G02770
MNL_G02770_V02_20170328
Advertisement
Table of Contents
Related Manuals for Goldblatt G02770
Summary of Contents for Goldblatt G02770
- Page 1 # G02770 ® 4.1 A 115 mm Tile Wet Saw Español página 17 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date MNL_G02770_V02_20170328 Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-876-7562, 8 a.m. - 5 p.m.,CST, Monday - Friday.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety rules......................Safety symbols...................... Technical specifications..................Package Contents....................Assembly....................... Operation......................Maintenance......................Troubleshooting guide..................Warranty....................... -
Page 3: Safety Rules
SAFETY RULES WARNING To avoid serious personal injury, do not attempt to use this product until you read the manual thoroughly and understand it completely. Save this manual and review frequently for continuing safe operation and instructing others who may use this tool. - Page 4 SAFETY RULES 11. The product may be used only when in a faultless condition. If the product or part of the product is defective, have it repaired by an expert. 12. Always follow the applicable national and international safety, health and labour regulations.
- Page 5 SAFETY RULES 5. CHECK DAMAGED PARTS. Before further use of the tool, a guard or other part that is damaged should be carefully checked to determine that it will operate properly and perform its intended function - check for alignment of moving parts, binding of moving parts, breakage of parts, mounting, and any other conditions that may affect its operation.
- Page 6 SAFETY RULES 13. Make regular checks to ensure that the cutting disc is correctly fastened. 14. Make sure that during the cutting operation, an adequate quantity of cooling water reaches the cutting surfaces of the disc at all times. 15. Never cut wood or metal with this saw. 16.
- Page 7 SAFETY RULES RESIDUAL RISKS Even when the product is used properly and in compliance with all the safety precautions in these instructions for use, the following residual risks can arise: • Touching the cutting disc in the exposed area. • Reaching into the spinning cutting disc. •...
- Page 8 SAFETY RULES with or without yellow stripes is the equipment-grounding conductor. If repair or replacement of the electric cord or plug is necessary, do not connect the equipment-grounding conductor to a live terminal. Check with a qualified electrician or service personnel if the grounding instructions are not completely understood, or if in doubt as to whether the tool is properly grounded.
- Page 9 SAFETY RULES C. EXTENSION CORDS (FIG. C) Minimum gauge for extension cords (FIG. C) Volta Total length of cord in feet Ampere Rating 120 V 25 ft 50 ft 100 ft 150 ft More Than Not More Than Not Recommended 1.
-
Page 10: Safety Symbols
Risk of injury when instructions Wear gloves are not followed Waste electrical products should Wet conditions alert not be disposed of with household waste TECHNICAL SPECIFICATIONS Code G02770 Model TC115I Voltage 120V~ 60Hz 4.1AMP No load speed 5300 RPM Insulation class Class I Dimensions of the diamond disc 4-1/2"... -
Page 11: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Tile saw (assembled) Protective guard Mitre cutting guide Parallel guide Metal bracket Diamond disc Spanners Rubber feet Water reservoir plug ASSEMBLY This tile saw must only be used only to cut tiles to a required size or shape. It shall not be used to cut inflammable, explosive or toxic materials. - Page 12 ASSEMBLY Unpacking • Remove all packaging materials. • Remove remaining packing and package inserts (if included). • Check that the package contents are complete. • Check the appliance, the power cord, the power plug and all accessories for transportation damage. •...
- Page 13 ASSEMBLY • Replace the outer flange and nut and tighten securely with the two spanners provided (fig. 8). Check that both blade flanges are in contact with the blade. • Unscrew the screw & washer from the metal bracket (fig. 9). fig.9 fig.10 •...
-
Page 14: Operation
ASSEMBLY FILLING THE WATER TANK (Fig. 17) Before cutting, the tank must be filled with water: • Unplug the tile saw from the mains supply. • Remove the cover from the working table. • Fill the tank with water to above the fill line (fig. 17a). •... -
Page 15: Maintenance
OPERATION MAKING A MITRE OR DIAGONAL CUT (Fig. 19) Follow the same procedure for a straight cut but use the mitre cutting guide in conjunction with the parallel guide. The mitre cutting guide simply clips onto the parallel guide. Make sure that the tile is held firmly in the fig.19 guide before maing the cut. -
Page 16: Warranty
TROUBLESHOOTING GUIDE POSSIBLE CORRECTIVE SYMPTOM CAUSE(S) ACTION Motor not running. No mains voltage? Check cable, plug, socket and fuse. Motor runs, cutting Flange nut loose? Check the flange is disc remains still seated correctly and when subject tighten if necessary. to load.
