Hanover Outdoor Furniture
If you have any problems with this product (missing or damaged parts, assembly issues, etc.),
PLEASE DO NOT RETURN TO THE RETAILER/STORE
Please call our Toll‐Free Customer Service Hotline at:
Between 9:00 AM and 5:00 PM Eastern Time, Monday through Friday
Or visit our website at:
To expedite any future warranty claims, please retain the Instruction Sheet, Warranty
Card and receipt for future use.
For additional on‐line support on assembly, troubleshooting and care & maintenance of your outdoor
furniture, please visit our website at: www.hanover‐products.com.
IMPORTANT
from where you purchased the product.
www.hanover‐products.com
1‐800‐416‐3511
6/1/2015 (a)
Advertisement
Table of Contents
Related Manuals for Hanover TRADTILE5PCFP-RED
Summary of Contents for Hanover TRADTILE5PCFP-RED
- Page 1 Hanover Outdoor Furniture IMPORTANT If you have any problems with this product (missing or damaged parts, assembly issues, etc.), PLEASE DO NOT RETURN TO THE RETAILER/STORE from where you purchased the product. 1‐800‐416‐3511 Please call our Toll‐Free Customer Service Hotline at: Between 9:00 AM and 5:00 PM Eastern Time, Monday through Friday www.hanover‐products.com Or visit our website at: To expedite any future warranty claims, please retain the Instruction Sheet, Warranty Card and receipt for future use. For additional on‐line support on assembly, troubleshooting and care & maintenance of your outdoor furniture, please visit our website at: www.hanover‐products.com. 6/1/2015 (a) ...
- Page 2 Outdoor Furniture 1-Year Limited Warranty Program For a period of one (1) year after purchase, the Manufacturer will either repair or replace defective components in accordance with this Limited Warranty. This warranty is between Manufacturer and the original purchaser and is valid only when accompanied by the original purchaser’s sales receipt showing original date of purchase and location of purchase.
- Page 3 Care & Maintenance Outdoor furniture can be enjoyed for many years when well maintained. Regular Maintenance Wash the furniture with a solution of mild detergent and water, rinse with clear water, and dry thoroughly. To all metal frames, apply a fine, clear automobile wax for maximum protection against harmful ultraviolet exposure and salt air.
- Page 4 ASSEMBLY INSTRUCTIONS Attach the leg support to the chair legs(B1 & B2) by using the 1/4"x20 mm bolts and washers as shown in Fig 1 Guide these bolts through the holes in the leg support into pre-drilled holes in the chair legs. Hand tighten only Attach the support bar to the chair legs by using the 1/4"x20 mm bolts and washers as shown in .
- Page 5 PARTS IDENTIFICATION LIST * NOTE: PARTS SHOWN ON PARTS LIST ARE NOT TO SCALE PARTS LIST DESCRIPTION ORDER PART # AR19986 CHAIR FRAME LEFT LEG AR19987 RIGHT LEG AR19988 SUPPORT BAR AR19989 LEG SUPPORT AR19990 1/4" X 20 MM HW0465 BOLT 5/16"...
- Page 6 ASSEMBLY INSTRUCTIONS ARL00200 CSA Model99010 Installer: Leave these instructions with consumer. Consumer: Keep these instructions for future reference DANGER WARNING: If you smell gas: Improper installation, adjustment alteration, 1. Shut off gas to the appliance. service or maintenance can cause injury or 2.
-
Page 7: Table Of Contents
TABLE OF CONTENTS Important Safety Information Important About Propane Specifications Parts Identification List Installation 7-11 Batteries Lighting Instructions Maintenance Troubleshooting Guide Warranty... -
Page 8: Important Safety Information
IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54; International Fuel Gas Code. ; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, B149.2, as applicable. -
Page 9: Important About Propane
IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS A self contained LP-gas cylinder for use with this appliance must have a capacity of 20 lbs. and must be equipped with a Type 1 connector and an OPD (overfill protection device). See Figure 1. The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specification for LP-gas cylinders of the U.S. -
Page 10: Parts Identification List
PARTS IDENTIFICATION LIST PART DESCRIPTION PART# CONTROL KNOB FP1245 GAS VALVE FP0307 THERMOCOUPLE FP0004 LP REGULATOR 65-FP-0181 HOSE ELECTRODE 65-FP-0128 ORIFICE ELBOW FP0310 IGNITION FP0006 MODULE PROPANE ZCF0021 ORIFICE “AAA” HW0705 BATTERY(1.5V) LAVA ROCK SET FP0002 FOOTCAP FC0743 1/4" X 15 MM BOLT HW0034 1/4"... - Page 11 TABLE RIM BACK PANEL LEFT SIDE PANEL RIGHT SIDE PANEL DOOR PANEL LP SUPPORT TILE-1 TILE-2 MIDDLE SUPPORT TABLE COVER BOTTOM/ TOP CONNECTOR...
-
Page 12: Installation
INSTALLATION 1. Identify parts packed in carton against the parts list. Remove all protective materials and set parts on a flat, non-abrasive surface. 2. Attach the back panel to side panels by using four 1/4"x40 mm bolts and washers as shown in Figure 2. - Page 13 5. Put the door onto the "L" connector (pre-assembled), guide the pin on the lower "L" connector into the hole under the door. Then guide the pin on the upper "L" connector into the hole in the upper portion of the door. Use a 1/4"x15 mm bolt and washer to secure the "L"...
- Page 14 8. Place gas tank onto the LP support as shown in Figure 8. Figure 8 9. Attach the metal ring (as shown in Figure 9) pre-fitted with gas hose which is connected to the table top, into the hole of the door panel, then use hex bolt driver to screw 1/4"x5mm nut, the gas tank has fixed as shown in Figure 10.
- Page 15 10. After making any necessary adjustments to the parts, use the hex bolt driver to tighten all bolts. Note: each bolt must be tightened a few revolutions at a time. Repeat until all bolts are tight. Do not over tighten. Over tightening may strip bolts. Cover all bolts with covers.
-
Page 16: Batteries
14. Open the tank valve. Apply a solution of soapy water to the tank-regulator connection and to the valve-hose connection to check for leaks as shown in Figure 14 If soap bubbles continue to form, the connection has a leak. If a leak is found, close the tank valve and tighten all connections. -
Page 17: Lighting Instructions
LIGHTING INSTRUCTIONS Warning: If these instructions are not followed exactly, a fire or explosion may result in causing property damage, personal injury or loss of life. Make sure the control knob is in the "OFF" position. See Figure 16 Open the tank valve all the way. -
Page 18: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM CAUSE REMEDY Check that gas tank valve is open. Turn control knob to “ON” No Propane Gas at Burner and push control knob in. Make sure tank has propane gas. Check that AAA battery is installed with negative (-) end first and has a charge. -
Page 19: Warranty
90 DAYS LIMITED WARRANTY What is Covered Under This Warranty? The item you have purchased is warranted against defects in materials and workmanship for the following parts as outlined below only when unit is installed and operated in accordance with the instructions in this Owner’s Manual and in compliance with local building and fire codes: ...
