- Page 1 MODEL：SLi1000 Installation instructions and manuals Installation instructions for skilled technicians! After installation, please hand over the installation instructions to the user.
- Page 2 IMPORTANT SAFEGUARDS READ ALL INSTRUCTION BEFORE USING When using the electronic product, especially in the presence of children, basic safety precautions should always be followed, including the following. Please read all instructions before use. 1.Do not use while bathing. 2.Do not place or store the product where it may fall or be dragged into a bathtub or sink. 3.Do not place in or drop into water or other liquid.
- Page 3 Suggestions on water supply connection Technical drawings Battery box removal distance >80mm Pit spacing 305mm/12.01in 701mm/27.6in NOTE: It is necessary to install the provided angle stop in an accessiable area for quick shutoff in case of an emergency.
-
Page 4: Precautions Before Use
Precautions before use In order to avoid personal injury and property damage to users and other people, please read the following safety precautions carefully and strictly observe them. After reading, please keep this manual in a drawer where you can access easily. ☆It is strictly forbidden to disassemble, repair or transform the product by yourself, otherwise it may cause fire or electric shock. - Page 5 ☆This appliance is provided with a protective device that may make the appliance inoperable under some abnormal conditions(such as immersion of the appliance).If NOTICE the appliance becomes inoperable,contact the STUDIOLUX service team. ☆Do not let children play with this product. ☆Do not supply water to the product before installation completed.
-
Page 6: List Of Materials
1.List of materials MODEL：SLi1000 Installation instructions and manuals Installation instructions for skilled technicians! After installation, please hand over the installation instructions to the user. Installation card User manual (Warranty card） Product Material Number:1606106910-001 Material Number:1606106864-001 Multitap nut Material Number:1403K110212 Anchor screws... - Page 7 3.2 Install Toilet and Toilet Wax Ring( For Option B installation, please see template.) Install the floor drain cover connector(not included) . Position correctly the two fixing bolts of the floor drain. Holding manner： Firstly, open the cover and seat; as the toilet is heavy, Insert the wax ring(not included) Position the toilet on the floor lifting the product by two...
-
Page 8: Product Function
4. Product function 1.Button operations Press (about 1s) and release side button to full flush. 2.The mechanical seat switch function While sitting on seat, the mechanical seat switch will be on to detect whether the user is on seat. The mechanical seat switch on about 10s, achieve full flush after leaving seat 6s. - Page 9 6.Replacement of power Unplug When the battery box Unplug and take out the Press the button of the pops up, pull out it. battery box. battery box. Replace Tip:※Used up Insert batteries should be thrown into corresponding Put back the battery box, type of garbage Put back the battery box and press the button of the...
-
Page 10: Cleaning And Maintenance
Bidet seat installation (3) Place the gasket on both sides of （1）connect and tight the three (2) Align the location hole of Bidet braided hoses to Bidet seat by the Bidet seat, lock the screw and seat with toilet bowl guide pillar, press wrench, then insert the hose and insert the rubber pads. -
Page 11: Warranty Card
Warranty card Product model Manufacturing number Customer name Sales company Date of purchase The 2nd copy send back... - Page 12 Maintenance record Maintenance personnel Date of maintain Maintenance items Maintenance company signature There may be differences between the contents of this manual and the real object. Please refer to the real object.If the products and attachments have any update, we will not notice. 1606106422-001 1.0 Type of Flush valve:FCS-6-KM-3 US Office...
