- Page 1 User Manual GP-206RT User Manual Please read the user manual carefully before start using the device.
-
Page 2: Table Of Contents
Table of contents 1. Components & Specification · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2. Getting Started · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3. -
Page 3: Components & Specification
1. Components & Specification Components Call button Pager Power adapter User Manual Transmitter-charging dock Antenna (6pcs) (DC 8V/3A) Specification Pager (GP-200R) Transmitter-charging dock (GP-206T) Frequency FSK/433MHz Frequency FSK/433MHz Power source DC 3.7V/180mA Power source DC 8V/3A Battery Lithium-polymer battery Antenna type SMA type Dimension W53 x L105 x H11(mm) -
Page 4: Settings
⑪⑧⑩⑩⑦⑫ Initialization 3-1. Channel Number Setting [Setting code: 664231] User can prevent the signal interference with the neighboring Syscall systems by setting their own channel number. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~”... -
Page 5: Group Number Setting
Set channel number 3 → press 1 and 2 3-2. Group Number Setting [Setting code: 664232] User can prevent the signal interference with the neighboring Syscall systems by setting their own group number. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~”... -
Page 6: Pager Ring Time Setting
3-3. Pager Ring Time Setting [Setting code: 664233] User can set the pager ring time. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~” noise) 2. Press 6-6-4-2-3-3 to enter the pager ring time setting mode. -
Page 7: Other Settings
3. Press the number to be registered to the pager. Check if the LED flashes. And then, take the relevant pager off from the dock 4. Press and hold 6 to save and return to previous menu. 3-5. Other Settings 3-5-1. -
Page 8: Exit From Settings
3. Press the applicable button to set * Anti-theft function: Alert on transmitter. (LED blink & Sound) Anti-theft and/or Out-range. * Out-Range function: Alert on Pager. (Sound) 1 2 3 Button - - - Anti-theft Out-range Save&exit Setting value 4. Press 6 to save and return to previous menu. 3-6. -
Page 9: Call Button On/Off
3-8. Call Button ON/OFF [Setting code: 664242] User can inactive call buttons on the transmitter-charging dock when there are lost or not in use pagers. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~”... -
Page 10: Call Button Selection
3-10. Call Button Selection [Setting code: 664246] User can set whether to use the pagers as 1~6 or 7~12. This feature is required when 2 sets of GP-206RT are used in the same place. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~”... -
Page 11: Initialization
3-12. Initialization [Setting code: 524416] User can initialize the registered pagers and the transmitter. But this is only applicable when the Gn, Pn of the pagers and the transmitter are matched up together. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~”... - Page 12 SYSCALL France - www.syscallglobal.fr 0033 (0)1 84 17 61 81 - contact@syscall.fr 242 boulevard de Stalingrad 94500 Champigny sur Marne, France Manufacturer ■ NTTWORKS CO., LTD 413-9 NTTWORKS Bldg, Galhyun-Dong, Eunpyong-Gu Seoul, Korea...
