- Page 1 GP-210RT USER MANUAL Pager all in one...
-
Page 2: Table Of Contents
Table of contents 1. Components & Specification · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3 2. Getting Started · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3 3. -
Page 3: Components & Specification
1. Components & Specification Components Call button Pager Power adapter User Manual Transmitter-charging dock Antenna (10pcs) (DC 8V/3A) Specification Pager (GP-200R) Transmitter-charging dock (GP-210T) Frequency FSK/433MHz Frequency FSK/433MHz Power source DC 3.7V/180mA Power source DC 8V/3A Battery Lithium-polymer battery Antenna type SMA type Dimension W53 x L105 x H11(mm) -
Page 4: Settings
Pager · Insert all pagers into the transmitter-charging dock in order to start charging. Power · The Red LED on the pager turns on while it is Adapter charging, and switches to Blue LED when it is fully charged. 3. Settings Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~”... -
Page 5: Channel Number Setting
3-1. Channel Number Setting [Setting code: 631] User can prevent the signal interference with the neighboring Syscall systems by setting their own channel number. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~”... -
Page 6: Pager Ring Time Setting
[Example ‒ Pn/Gn number setting] Button Pn/Gn number 3-3. Pager Ring Time Setting [Setting code: 633] User can set the pager ring time. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~” noise) 2. -
Page 7: Pager Number Setting
3-4. Pager Number Setting [Setting code: 634] Pager registration 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~” noise) 2. Press 6-3-4 to enter the pager number setting mode. -
Page 8: Anti-Theft & Out-Range Setting
3-5-2. Anti-Theft & Out-Range Setting [Setting code: 635] When the distance between transmitter and pager goes beyond the wireless range, either the transmitter or pager starts alert after 10 or 16 minutes respectively. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~”... -
Page 9: Rf Test Mode
3-7. RF Test Mode [Setting code: 641] User can verify the channel number (Pn), group number (Gn) and the call number of the pager when the RF test mode is on. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~”... -
Page 10: Call Button On/Off
3-8. Call Button ON/OFF [Setting code: 642] User can inactive call buttons on the transmitter-charging dock when there are lost or not in use pagers. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~”... -
Page 11: Call Button Selection
3-10. Call Button Selection [Setting code: 646] User can set whether to use the pagers as 1~10 or 11~20. This feature is required when 2 sets of GP-210RT are used in the same place. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~”... -
Page 12: Initialization
3-12. Initialization [Setting code: 656] User can initialize the registered pagers and the transmitter. But this is only applicable when the Gn, Pn of the pagers and the transmitter are matched up together. 1. Press and hold 5 for about 10 seconds and the device becomes input standby mode (Press and hold until it makes “Beep~~”...
