CONTROL CONCEPTS, INC. warrants that the products delivered will be as described in the sales order or contract. CONTROL CONCEPTS, INC. warrants to the original user that CONTROL CONCEPTS, INC. products will be free from defects in materials and workmanship for a period of two (2) years after the date CONTROL CONCEPTS, INC. ships such products.
TABLE OF CONTENTS DECLARATION OF CONFORMITY .....................ii CERTIFICATE OF COMPLIANCE ....................iv 1. RECOMMENDED FUSING ..................... 1 2. INSTALLATION ........................2 2.1 Mounting Considerations for All AC Controllers ............2 2.1.1 Single Phase One Zone (50-400 Amps) ............3 2.1.2 Single Phase, Two Zone (50-400 Amps) ............4 Three Phase - Two Leg (50-400 Amps) ..............
Model Numbers: Model Fusion followed by ZC, PA or DC, followed by 1, 2 or 3, followed by 1 through 9 or A through E, followed by O, S or E, may be followed by numbers and/or letters, may be followed by numbers and/or letters, may be followed by NS, may be followed by numbers and/or letters.
Page 6
External EMI filters must be used in conjunction with the FUSION series power controllers to maintain CE immunity* approval. The following filters were used during the immunity testing. Universal input power: Line input power: Schaffner filter Schaffner filter P/N: FN 2030-3-06 P/N: FN 3270H-35-33 The Schaffner filter for universal input power, or it’s equivalent, may be used as listed above.
CERTIFICATE OF COMPLIANCE CERTIFICATE OF COMPLIANCE This document certifies that Control Concepts, Inc’s products listed in the table are fully RoHS complient as of Nov 13, 2009 in accordance with EU RoHS Directive 2002/95/EC. The products listed in the table have been identified as RoHS compliant do not exceed the maximum limit for the six substances: Lead, Mercury, Cadmium, Hexavalent chromium, Polybrominated biphenyls and Polybrominated diphenyl ether.
It is important to leave enough room for the removal of the connectors (approximately 1.00 [25.4] - More if using Remote Display) and wiring considerations. CAD Blocks are available for download at www.ccipower.com. FUSION Installation Manual Revision 3.50.3 www.ccipower.com 1-800-765-2799...
3. WIRING Control Concepts configures and tests each controller before shipping. Once received, the controller is ready to install. The following sections will describe how to properly wire the unit with the recommended fusing. For line and load connections use copper conductors rated 75°C minimum. In the wiring drawings the wire acceptance is listed with the entry heights.
This figure shows a single phase controller connected Phase A to Phase B. The controller is not phase sensitive and can be connected to any two phases. It can also be connected from Phase to Neutral. FUSION Installation Manual Revision 3.50.3 www.ccipower.com 1-800-765-2799...
The controller is not phase sensitive and any zone can be connected to any two phases. Any or all zones can be connected from Phase to Neutral. Note: During operation Zone 1 must have line power “ON” in order for other zones to operate. FUSION Installation Manual Revision 3.50.3 www.ccipower.com 1-800-765-2799...
This figure shows a three phase two leg controller connected to either a Delta or 3 Wire Wye load. Note: An optional current transducer may be ordered for monitoring the current on the third leg that does not run through the controller. Contact Control Concepts for more details. FUSION Installation Manual Revision 3.50.3 www.ccipower.com...
Wire Wye operation. The Fusion controllers normally display line and load voltages from Line to Line. When the controller is in 4 Wire Wye operation the line voltages read Line to Line while the load voltages read Line to Neutral.
POT 1 POT 2 Note: The FUSION power controller has two analog setpoints: SP1 and SP2. On a single zone controller, either can be selected to control this zone. On a 2 zone controller, SP1 is used to control zone 1 and SP2 is used to control zone 2. On controllers with more than 2 zones, a digital interface must be ordered for communication with all zones.
When using this feature, one and only one controller should have the SYNC-GUARD™ resistor enabled via the Fusion Control Panel. See Fusion Control Panel software manual for more details. The figures below show the total current as a...
Voltage output: 0-10 Vdc, 20 mA max Current output: 0-20 mA, 15 Vdc compliance For selecting voltage or current mode for the retransmits, connecting to the Fusion Control Panel Software is required. See the Fusion Control Panel Software manual for details.
