Control Concepts ATOM Quick Start Manual

OPERATING SEQUENCE
1. Install the controller in the desired location with appropriate clearance as shown in the Panel Layout.
2. Attach and wire the 6-pin connector as shown in the Connector section.
3. Wire Line and Load connections as shown in the Wiring Diagram.
4. Apply 24 Vdc power to the command connector pins 5 and 6 to initiate controller startup.
The Power (PWR) LED will be red when the unit is powered on and no AC line voltage is present.
5. Apply Line Voltage.
The Power (PWR) LED will be green when the unit is powered on and AC line voltage is present.
6. Place the controller in RUN state by setting Digital Run Enable [SP-25] to RUN (1)
7. Apply a Digital or Fieldbus Setpoint command greater than zero
8. Check controller LEDs for proper controller operation.
The Status (STAT) LED will be green when the unit is outputting. The brightness of the Status LED is proportional to the setpoint command.
If the controller is not outputting as expected refer to the LED Indicators and Troubleshooting section for help.
1
When in SSR firing modes the setpoint command must be 100% to enable output.
Rev: 1.6 Rev: 1.6
© Control Concepts Inc. 2024
Three Phase EtherCAT
QUICK START GUIDE
to enable controller output.
1
www.ccipower.com www.ccipower.com
www.ccipower.com 1-800-765-2799
ATOM
16 - 80 Amp
WARNING: Ensure all high voltage is off and
disconnected before wiring the controller.
Always wire in accordance with local codes.
1-800-765-2799 1-800-765-2799
ATOM EtherCAT
1
© Control Concepts Inc. 2024 Rev: 1.6
