We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part #
Description
F
A
AN
SSEMBLIES
4 Ft, 8 Ft & 12 Ft
A. 7W Standard Fan Assembly
0058698
Fan Motor, Evaporator
(MO.4410102)
0142780
Fan Blade (FB.0142780)
7W Energy Efficient Fan Assembly
0477654
Fan Motor, Evaporator
(MO.4410545)
0142780
Fan Blade (FB.0142780)
6 Ft Only
A. 4W Standard Fan Assembly
0392457
Fan Motor, Evaporator
(MO.4410101)
0382383
Fan Blade (FB.4780617)
4W Energy Efficient Fan Assembly
0477653
Fan Motor, Evaporator
(MO.4410544)
0382383
Fan Blade (FB.4780617)
Note: Revision B changes ballast (
©2008 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
B
D
C
E
A
Wiring Item #
(1)
(1)
(1)
(1)
); adds optional LED lighting (
Page 1
D
F
E
Item Part #
Description
B. 0411744
Standard Non-adjustable
Defrost Thermostat
(CT.0411744)
C. Optional Adjustable Refrigeration Thermostat (3)
L
. B
, LED F
AMPS
ALLASTS
D. Ballast, Electronic
0480130
2 lamps (BA.4481676)
0480131
3 lamps (BA.4481654)
0480132
4 lamps (BA.4481677)
E.
Fluorescent Lamp
Replace with like fixtures
F. 0501213
Power Supply (EP.4481861)
G.
LED Fixture
Replace with like fixtures
); adds capacity and weight (
Pages 1, 3, 4, 8
P2NX-E
Technical Data Sheet
P/N 0478824_B
NSF
®
Certified
March 2008
E
G
Wiring Item #
P
S
IXTURES AND
OWER
UPPLY
Page 5
P/N 0478824_B
(2)
(4)
(5)
(6)
(7)
).
