- Page 1 DALLARA iR-01 U S E R M A N U A L...
-
Page 2: Table Of Contents
Table of Contents CLICK TO VIEW A SECTION GENERAL INFORMATION » A Message From iRacing » Tech Specs » Introduction » Getting Started » Loading An iRacing Setup » Dash Pages » Race » Qual ADVANCED SETUP OPTIONS » Tires »... -
Page 3: A Message From Iracing
DE AR i R ACING US ER , Congratulations on your purchase of the Dallara IR-01! From all of us at iRacing, we appreciate your support and your commitment to our product. We aim to deliver the ultimate sim racing experience, and we hope that you’ll find plenty of excitement with us behind the wheel of your new car! -
Page 4: Tech Specs
DALLARA iR01 | TECH SPECS CHASSIS C A RBON FIB RE A LUMI NUM C ON S T RUC T IO N W E T W E I G H T L E N G T H W I D T H W H E E L B A S E D R Y W E I G H T W I T H D R I V E R... -
Page 5: Introduction
To that end, we have provided baseline setups for each track commonly raced by these cars. To access the baseline setups, simply open the Garage, click iRacing Setups, and select the appropriate setup for your track of choice. If you are driving a track for which a dedicated baseline setup is not included, you may select a setup for a similar track to use as your baseline. -
Page 6: Loading An Iracing Setup
Upon loading into a session, the IR-01 will automatically load the iRacing Baseline setup [baseline.sto]. If you would prefer one of iRacing’s pre-built setups that suit various conditions, you may load it by clicking Garage > iRacing Setups > and then selecting the setup to suit your needs. -
Page 7: Dash Pages
DALLARA iR01 | DASH PAGES Dash Pages “RACE” PAGE LEF T CL US T ER Engine RPM SPEED Vehicle Speed (MPH or KPH, depending on selected units) BRAKE BALANCE % Front brake bias PEDAL Currently selected throttle map setting FARB Current Front Anti-Roll Bar blade setting RARB Current Rear Anti-Roll Bar blade setting... -
Page 8: Qual
DALLARA iR01 | DASH PAGES “QUAL“ PAGE LEF T CL US T ER Engine RPM SPEED Vehicle Speed (MPH or KPH, depending on selected units) BRAKE BALANCE % Front brake bias PEDAL Currently selected throttle map setting FARB Current Front Anti-Roll Bar blade setting RARB Current Rear Anti-Roll Bar blade setting RIGH T C LUS T ER... -
Page 9: Advanced Setup Options
DALLARA iR01 | ADVANCED SETUP OPTIONS | TIRES ADVANCED SETUP OPTIONS This section is aimed toward more advanced users who want to dive deeper into the different aspects of the vehicle’s setup. Making adjustments to the following parameters is not required and can lead to significant changes in the way a vehicle handles. -
Page 10: Tire Settings
DALLARA iR01 | ADVANCED SETUP OPTIONS | TIRES TIRE SETTINGS (ALL FOUR TIRES) C OLD AI R PRES SURE Air pressure in the tire when the car is loaded into the world. Higher pressures will reduce rolling drag and heat buildup, but will decrease grip. -
Page 11: Chassis
DALLARA iR01 | ADVANCED SETUP OPTIONS | CHASSIS Chassis The Dallara IR-01 features a simplified suspension design which forgoes dedicated springs for each corner of the car, as you would see in a road car or most other race cars. Instead, heave (pitch) and roll are handled independently via front and rear Heave Springs and Anti-Roll Bars, respectively. - Page 12 DALLARA iR01 | ADVANCED SETUP OPTIONS | CHASSIS A RB BL ADES The configuration of the Anti-Roll Bar arms, or “blades”, can be changed to alter the overall stiffness of the ARB assembly. Higher values transfer more force through the arms to the ARB itself, increasing roll stiffness in the front suspension and producing the same effects, albeit on a smaller scale, as increasing the diameter of the sway bar.
-
Page 13: Corners
DALLARA iR01 | ADVANCED SETUP OPTIONS | CHASSIS CORNERS (ALL FOUR SECTIONS) C ORNE R W EIGH T This displays the weight on each wheel while sitting in the garage under static conditions. Useful for determining weight distribution. RIDE HEIGH T Chassis Ride Height is the distance from the ground to a reference point on the bottom of the chassis. -
Page 14: Rear
DALLARA iR01 | ADVANCED SETUP OPTIONS | CHASSIS REAR A RB S T I FF NES S The ARB (Anti-Roll Bar) stiffness setting adjusts the roll stiffness of the rear suspension via a change in the ARB’s diameter. Increasing the ARB stiffness will increase the roll stiffness of the rear suspension, resulting in less body roll but increasing mechanical oversteer. - Page 15 DALLARA iR01 | ADVANCED SETUP OPTIONS | CHASSIS S PRI NG DEFLEC T IO N This displays how much the Heave Spring is compressed from its total length under static loads in the garage. B UMP S T IFF NES S Bump stiffness affects how resistant the shock is to compression (reduction in length).
-
Page 16: Vehicle System
DALLARA iR01 | ADVANCED SETUP OPTIONS | VEHICLE SYSTEMS Vehicle Systems AERO FRON T W ING ANGLE The Front Wing Angle setting changes the Angle of Attack of the front wing elements. Increasing wing angle increases the downforce generated by the wing but increases drag, while decreasing the wing angle reduces the downforce generated by the wing while reducing drag. -
Page 17: Differential
DALLARA iR01 | ADVANCED SETUP OPTIONS | VEHICLE SYSTEMS DIFFERENTIAL C OAS T R AMP ANGLE Differential ramp angles alter how much force is produced to keep the differential locked. Coast Ramp Angles affect the differential under deceleration, with higher numbers generating less locking force and lower numbers generating more locking force. -
Page 18: Fuel
DALLARA iR01 | ADVANCED SETUP OPTIONS | VEHICLE SYSTEMS FUEL FUEL L E V EL Fuel level is the amount of fuel in the fuel tank when the car leaves the garage.\ BRAKE SYSTEM FRON T M AS T ER CY LIN DER The Front Brake Master Cylinder size can be changed to alter the pressure in the lines to the front brake calipers. -
Page 19: Steering System
DALLARA iR01 | ADVANCED SETUP OPTIONS | VEHICLE SYSTEMS STEERING SYSTEM S T E ERI NG PINION R AT IO The size of the steering pinion can be changed to alter how fast or slow the steering feels to the driver. The value represents the amount of steering rack movement for a single revolution of the steering pinion, with larger values resulting in a faster steering feel.
