PARTS LIST
Item
Quantity
D5RRI
D5RRIS
1.
1
2.
1
3.
9
4.
9
5.
9
6.
1
7.
2
8.
2
9.
1
Note: Nut retainers are factory installed in the left end, and alignment pins are factory installed in
the right end of each merchandiser.
NOTES:
• Be sure merchandisers have been
leveled according to the installation
instructions.
• Be sure factory-installed nut
retainers and alignment pins are in
place.
• Install optional shelf kits after all
merchandisers have been joined.
Remove front air grille and
1
honeycomb from the right end
as shown in Figure 1.
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
®
Merchandisers
Description
1
1
Gasket
/
2
1
1
Gasket
/
2
5
Cap Screw
5
Lock Washer
5
Flat Washer
1
Threaded Rod
2
Flat Washer
1
2
Hex Nut
/
2
1
Silicone Sealer
Figure 1. Remove Air Grille and Honeycomb
D5RRI and D5RRIS
Rear Roll-in Dairy
1
x
/
x 60
(1524 mm)
2
5
x 1
/
x 120
(3048 mm)
8
5
1
/
-18 x 1
/
16
4
5
/
16
5
/
16
1
/
-16 x 12
(305 mm)
2
1
/
2
-16
Right Front
Honeycomb
Joining Instruction
D5RRI
D5RRIS
Right Front
Air Grille
P/N 0435047
January, 2003
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hussmann IMPACT D5RRI
Summary of Contents for Hussmann IMPACT D5RRI
- Page 1 • Install optional shelf kits after all merchandisers have been joined. Remove front air grille and honeycomb from the right end as shown in Figure 1. HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. ® D5RRI and D5RRIS Description Gasket x 60...
- Page 2 Verify that nut retainers and alignment pins are installed in the right-hand end of the left case in the locations shown in Alignment Pins Figure 2. Figure 2. Verify Nut Retainer and Alignment Pin Installation Alignment Pins HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
- Page 3 Joining Instruction for D5RRI and D5RRIS Rear Roll-in Dairy Merchandisers Note: Case To Be Sealed And Gasketed As Shown D5RRI in. x x 60 in. x 1 x 120 Figure 3. Apply Gaskets Optional Optional Low Front Low Front HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
- Page 4 Start at the bottom, then middle, then top; tighten until gaskets are compressed. Alignment Pins Figure 4. Joining Ends HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. ® Merchandisers Nut Retainer 9 Places for D5RRI and 5 Places for D5RRIS...
- Page 5 Joining Instruction for D5RRI and D5RRIS Rear Roll-in Dairy Merchandisers Figure 5. Canopy Joining Silicone Gun Silicone Gun Figure 6. Applying Silicone HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. D5RRI Apply Silicone Bead D5RRIS Apply Silicone Bead P/N 0435047 Draw canopies together using Rod –...
