Eurolube 26700 Manual

POWER RAM PUMP HOIST
PART NO 26700, 257-51, 257-52 / ART.NR. 26700, 257-51, 257-52
Description ................................................................................ 1
Warning and cautions ................................................................ 2
Installation ................................................................................. 2
Operation ................................................................................. 4
Optional equipments ................................................................. 5
Technical data ............................................................................ 6
Dimensions ................................................................................ 7
Spare pats .................................................................................. 8
Troubleshooting ....................................................................... 11
Declaration of conformity ........................................................ 12
Fixed inductor for the supply of grease, inks, etc. Operated by
compressed air. This unit uses two pneumatic cylinders connected
with a metal structure and protected with metal fairing fixed to
a reinforced base plate, resulting in a very robust piece of
equipment that is very small for the type of drums with which it
can work.
Samoa Industrial, S.A. · Box 103 Alto Pumarín · 33211 Gijón - Asturias Spain · Tel.: +34 985 381 488 · Fax.: + 34 985 384 163
Part and technical service guide
Fig. 1
www.eurolube.com
Content

Description

This unit, supplied with all the components necessary for its use,
was designed to supply grease with the greater guarantee of
priming of the pump, and maximum use of the grease drums,
compatible with this model of inductor.
It incorporates a robust aluminium inductor plate, which has a
sealing system made up of lip seals or double O-rings. This system
guarantees the walls of the drum are clean and that it is perfectly
sealed, which stops impurities getting in or simply protects from
the weather. The model and material of the lip or seal used
depends on its compatibility with the substance pumped. There
are also different pump kits designed to optimise the work
depending on the use required of this unit.
When the unit is correctly secured, the plate can be raised
together with the pump to a given height to facilitate changing
the used drum.
This unit has a control cabinet for the inductor and for the pump
installed in the unit. This control cabinet has all the systems
necessary to facilitate the inductor plate going into and out of
the drum.
Part No.:
391 000
424 000
R. 09/12 842 806
