Fencee MX10 User Manual

Remote monitoring of fence parameters
Hide thumbs Also See for MX10:
Table of Contents

Advertisement

Quick Links

Download this manual
EN
User
manual
REMOTE MONITORING
OF FENCE PARAMETERS
WORKS ONLY IN CONJUNCTION WITH:
Wireless RF connection with the Gateway.
IT DOES NOT NEED A SIM CARD
No additional operating costs.
www.fencee.eu
Electric fencing
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX10 and is the answer not in the manual?

Questions and answers

Related Manuals for Fencee MX10

Summary of Contents for Fencee MX10

  • Page 1 User manual REMOTE MONITORING OF FENCE PARAMETERS WORKS ONLY IN CONJUNCTION WITH: Wireless RF connection with the Gateway. IT DOES NOT NEED A SIM CARD No additional operating costs. www.fencee.eu Electric fencing...

  • Page 2: Table Of Contents

    Thank you for purchasing the MX10 Monitor from VNT electronics s.r.o. The device complies with the safety regulations according to the valid law as well as the relevant EU regulation (CE). The device complies with the Council of Europe Directive 2014/53/EC, meets the requirements of the General License of the Czech Telecommunication Office according to the general authorization No.

  • Page 3: Introduction

    • Power battery: 2 × C-LR14 • Dimensions: 78 × 144 × 42 mm • Weight: 325 g 4. PACKAGE CONTENTS • MX10 Monitor • Two C-LR14 batteries • Magnet with a string • Earthing pin • Earthing cable for grounding •...

  • Page 4: Description Of The Device

    Everything then communicates with the central Gateway and the energizer of the fencee power DUO RF PDX series (it is not part of the Monitor package). • Using radio frequency technology, it transmits the measured data wirelessly to the central Gateway, where the values are shown on the display.
  • Page 5 Inserting the batteries • Unscrew the screws and open the cover on the back of the Monitor. • Insert two C-LR14 batteries according to the instructions in the plastic cover. • Return the cover to its original position and tighten the screws firmly. An opening for the cable tie.

  • Page 6: Description Of Controls

    Control The device is controlled by the included magnet, which must be attached to the target on the side of the MX10 Monitor. When the magnet approaches, the status of the Monitor is indicated by an LED diode: Red = off Green = on If no LEDs light up, the batteries need to be checked and replaced.

  • Page 7: Pairing The Monitor With The Gateway Gw10

    7. PAIRING THE MONITOR WITH THE GATEWAY GW10 First, the MX10 Monitor must be paired with the Gateway in order to display the measured data. Pairing is performed by the following steps: Place the Monitor and Gateway next to each other, up to a maximum distance of approx.

  • Page 8: Connection With Gateway Gw10

    8. CONNECTION WITH GATEWAY The Monitor measures each pulse in the fence system and sends the values to the Gateway every 15 minutes. If a voltage lower than the set limit is measured , data is sent to the Gateway immediately and an alarm is triggered. Setting the low voltage alarm level on the fence system The 3 kV limit is set at the factory.

  • Page 9: Installing The Monitor On A Fence

    9. INSTALLING THE MONITOR ON A FENCE After pairing the Monitor with the Gateway, it is possible to place the Monitor in the desired location of measurement on the fence system. Before installation, it is necessary to turn off the energizer, in order to ensure safe handling. We install the Monitor as shown in Figure 4.
  • Page 10 Installation examples Place the Monitor where voltage monitoring is required (entrance TIP: to the fence system) or where frequent problems can be expec- ted, e.g. with vegetation, by the forest, by the water. Standard installation Fence system divided into zones. When the voltage drops on a particular Monitor, you can easily identify the zone and locate the problem.
  • Page 11 Installation at the entrance to the fence system Installation for easy identification of the fence system with a non-functional fence. FENCE 1 FENCE 2 FENCE 3 Figure 6: Installation at the entrance to the fence system Installation at the entrance to the fence system and problem areas Installation for easy identification of the fence with a non-functional fence.
  • Page 12 Control • Check • Keep informed WORKS ONLY IN CONJUNCTION WITH: 11.2 kV BAT 12,6 V ALARM 3kV Figure 8: Monitor, Gateway and fence connection RF energizer Monitor MX10 High-voltage connecting cable Gateway GW10 Conductor Earthing cable External RF antenna Line connector...
  • Page 13 BAT 12,6 V ALARM 3kV GATEWAY GW10 10.8 kV BAT 12.2 V ALARM 3 kV 10,5 kV BAT 100 % ALARM 3kV Monitor MX10 Tensioner Insulators Warning sign Gate Table 1: Insulator of gate Description of individual parts of the connection...

  • Page 14: Troubleshooting - Possible Fault Sources

    10. TROUBLESHOOTING - POSSIBLE FAULT SOURCES Cause Troubleshooting Pairing cannot be completed The surroundings is very noisy, or the signal between the Monitor and the Gateway is too weak. Try pairing the device with antennas closer to each other or in less noisy environment.
  • Page 15 New website An easy to orient e-shop BLOG I ADVICE I TIPS MANUALS FOR DOWNLOAD We are online...
  • Page 16 06102020 Seller‘s stamp and signature: Electric fencing VNT electronics s.r.o. Dvorská 605, 563 01 Lanškroun www.fencee.eu Czech Republic +420 730 893 828 info@fencee.eu fencee.cz fenceeczech Servis: +420 730 893 827...
