- Page 1 USER MANUAL Electric fencing AUTOMATIC SMART CHICKEN DOOR Manual for models Art.Nr. 8225, 8226, 8227 VNT electronics s. r. o. www.fencee.eu Dvorská 605, 563 01 Czech Republic +420 730 893 828...
-
Page 2: Table Of Contents
CONTENT Preparation ............ 3 Installatio+n . -
Page 3: Preparation
1. PREPARATION CONFIRM THAT THE SPACE IS LARGE ENOUGH. Before installing/assembling, make sure that you have enough space at the place of the intended installation/assembly. For smooth operation of the device, it is necessary to provide a minimum of 31 cm of space above the upper edge of the door, left, right, and below at least 3 cm from the edge of the device. -
Page 4: Installation
2. INSTALLATION 2.1. Use a screwdriver to unscrew the two screws that secure the battery cover. 2.2. Remove the battery cover and place two AA alkaline batteries inside (Don't use rechargeable batteries). Then close the battery cover and tighten the screws. 2.3. - Page 5 2.5. Drill holes in the marked corners to make it easier to use a jigsaw to cut out the door from the hole. 2.6. Use a jigsaw to saw off the opening by connecting the hole. 2.7. Before installing the door, please make sure that the installation surface of the door is flat and do not bend the door panel.
-
Page 6: Solar Panel Install
2. INSTALLATION 2.9. Press to test the door opening and closing. 3. 2 W SOLAR PANEL INSTALL (Art. Nr. 8228) 3.1. Fix the solar panel and the brackets with screws. 3.2. Place the solar panel slanted upward as shown, and fix the solar panel beside the door panel with four selftapping screws. -
Page 7: Set Up
4. SET UP Sensor Timer Warning Battery level Open and close state DOWN Open state OPENING CLOSING Close state DEFAULT MODE The door automatically works on default mode if not configured differently by the user. Default mode is sensor mode (Both open and close). ln the default mode, the door detects the ambient brightness through the light sensor, open when it detects daylight, and close when it is dark. -
Page 8: System Time Setting
4.1. SYSTEM TIME SETTING (12/24 HOUR) 1. Press any key to light up the screen, and then press to enter the settings. 2. Press to set the time convention, 12-hour or 24-hour. Then press to save and enter the current time setting. 3. -
Page 9: Closing Mode Setting
This mode is for automatic opening of the coop door at dawn using the light sensor, as shown below. The number on the left shows the current ambient light level, and the flashing number on the right is the desired light level you would like to set for opening the door. - Page 10 This mode is for the automatic closing of the coop door at the time you have set, as shown on the following figure. Press to set the hour when the hour flashes, press to confirm and enter the minute setting. Press to set the minute when the minutes flash, press to confirm...
-
Page 11: Anti-Pinch Function
When both are set, the door opener will use the Light Sensor as its primary reference for closing. If it is not dark enough to close using the Light Sensor, the default time you set will be used instead. 3. After the Closing mode setting, the screen displays SAVE, indicating the end of the setting up process. -
Page 12: Usage
6. USAGE Read all instructions. 1. Use two AA alkaline batteries to power the door. Never use rechargeable batteries. 2. lf the door has to be stored unused for an extended period, the batteries should be removed. 3. Before installing/assembling the door, make sure that you have enough space at the place of the intended installation/assembly. - Page 13 14. It is recommend to install the door in a dry place away from any rain. This will prolong the life span of the opener. 15. When there is a lot of dust on your chicken door, please clean it up in time.
-
Page 14: Technical Specifications
7. TECHNICAL SPECIFICATIONS Automatic chicken Automatic chicken Automatic chicken door door AC door AC + Solar Art.Nr. 8225 Art.Nr. 8227 Art.Nr. 8226 • Automatic door • Automatic door • Automatic door • User manual • User manual • User manual •... - Page 16 07022024 Electric fencing VNT electronics s.r.o. Dvorská 605, 563 01 Lanškroun www.fencee.eu Czech Republic...
