- Page 1 SYSTEM 7 September 2014 Vitreous Enamelled Steel Stove Pipes Tel: +353 46 95 58030 Fax: +353 46 95 58034 Email: sales@miflues.ie Web: www. miflues.ie...
- Page 2 MI-Flues System 7 Vitreous Enamelled Stove Pipe INTRODUCTION INSTALLATION Mi-Flues System 7 vitreous enamelled stove pipe Mi-Flues System 7 should be fitted at least four times has been specifically engineered to give an authentic the diameter of the pipe away from any combustible visual...
- Page 3 MI-Flues System 7 Vitreous Enamelled Stove Pipe LENGTHS ADJUSTABLE LENGTHS Available in 300mm, 500mm, 1000mm and 1200mm. Telescopic Joint Locking Screws To fit an adjustable length, loosen the locking screws 1000 1200 with a suitable screw driver. Adjust the telescopic Code Dia.
- Page 4 MI-Flues System 7 Vitreous Enamelled Stove Pipe 45° Bend 90° Bend With Door Used to provide a 90° change Used to provide a 45° of direction and includes a change of direction or can non corrosive stainless steel be used in pairs as an access door to facilitate offset.
- Page 5 Start Off Adaptor Mi-Flues can supply a coloured finished door (on request) as an This is used to connect an appliance to a System 7 alternative to the standard steel finish. pipe. It is available in 125mm and 150mm. Coloured finish door plus Rosette plate Dia.
- Page 6 Connection to System 2 twin wall chimney manufacturers installation instructions. When a System 7 flue pipe is joined to our System 2 twin wall insulated chimney which penetrates a Distance to Combustible materials...
- Page 7 Mi-Flues System 7 carries the following product recommended Mi-Flues System 7 45° bends. designation code. Within a run of system 7 flue no more than two EN1856-2 T600 N1 D Vm L80180 G (**) bends should be used. Two bends are used to Note: **4 x diameter of the flue create one offset.
- Page 8 All flue systems must be installed according to current Building Regulations. Mi-Flues has adopted a policy of continuous product review, and in the interests of development and improvement the Company reserves the right to vary the appearance and performance of any of its products without prior notice.
