Page 1: Operation Manual
® Merchandisers F2 Frozen Meat and Seafood Wall Merchandiser ® Certified Installation & Operation Manual Shipped With Case Data Sheets P/N 424382A.. Impact Series February 2001... -
Page 2: Table Of Contents
INSTALLATION NSF Certification ....1-1 Location ......1-1 Shipping Damage . -
Page 3: Installation
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) INSTALLATION SHIPPING DAMAGE All equipment should be thoroughly examined for ®... -
Page 4: Merchandisers Shipped With End Installed
NSTALLATION WARNING Do NOT remove shipping braces until the merchandisers are positioned for installation. MERCHANDISERS SHIPPED WITH END INSTALLED If the case was shipped with the end installed, two long bolts were used to hold the shipping brace to the end. If the shipping bolts are reinserted after removing the brace, they will extend into the product area. -
Page 5: Heater Mounting
LL JOINTS MUST BE AIR TIGHT TO PREVENT FORMATION OF ICE OR CONDENSATION HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) Prepare Case 1. Check to be sure that merchandisers are level and that the factory-installed nut retainers and alignment pins are in place. - Page 6 NSTALLATION IMPORTANT • Do not stretch gasket, especially around corners. • Do not butt gaskets; always overlap them as shown. • Remove paper backing after gasket has been applied. Tighten in order shown Alignment Pins Butyl Tape P/N 424382A Seal Merchandisers 1.
-
Page 7: Splashguard Bracket And Joint Support
Fasten with hex head sheet metal screws. Screw Joint Support HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) OFFSETTING BUMPERS AND TOP RAIL Offsetting the bumpers and glass trim helps to disguise the joint locations, giving the lineup a smoother look. - Page 8 NSTALLATION Starter Bumper Retainer 4. Install lower bumper starter and full length lower bumpers by simply pushing them into place. There are no internal joint trims on lower bumpers. 5. Return to left end of line up and position starter section of glass trim. 6.
-
Page 9: Refrigeration / Electrical
Fan Plenum Piping Locations HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) After connections have been made, seal this outlet thoroughly. Seal both the inside and the outside. We recommend using an expanding polyurethane foam insulation. -
Page 10: Insulation
EFRIGERATION INSULATION The suction and liquid lines should be clamped or taped together and insulated for a minimum of 30 ft (9144 mm) from the merchandiser. Additional insulation for the balance of the liquid and suction lines is recommended wherever con- densation drippage is objectionable or the lines are exposed to ambient conditions. -
Page 11: Merchandiser Electrical Data
ELECTRICAL CONNECTIONS All wiring must be in compliance with NEC and local codes. All electrical connections are to be made in the electrical raceway or Handy Box. HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) Optional Refrigeration Thermostat Bulb Optional... -
Page 12: Identification Of Wiring
EFRIGERATION IDENTIFICATION OF WIRING Leads for all electrical circuits are identified by colored plastic bands. These bands correspond to the color code sticker (shown below) located inside the merchandiser’s raceway. Leads for all electrical circuits are identified by a colored plastic band: neutral wire for each circuit has either White insulation or a White plastic sleeve in addition to the color band. -
Page 13: Drip Piping And Splashguards
D OUBLE WATER SEALS IN SERIES WILL CAUSE AN AIR LOCK AND PREVENT DRAINING HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) CAUTION Splashguard brackets MUST be installed before piping case. 3. Pitch the drip piping in the direction of flow. -
Page 14: Installing Splashguards
IPING AND INSTALLING SPLASHGUARDS The splashguard is shipped inside each merchan- diser. A merchandisers have been leveled FTER and joined, and all drip piping, electrical and refrigeration work has been completed, install the splashguard. To Install Splashguards: 1. Check to be sure that all splashguard brackets are level with the floor. -
Page 15: Start Up / Operation
T NO TIME SHOULD MERCHANDISERS BE STOCKED BEYOND THE LOAD LIMITS INDICATED LOAD LIMIT O NOT BLOCK HONEYCOMBS HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) START UP / OPERATION O NOT . This cap is to be STOCKING Product should NOT be placed in merchandisers until case is at proper operating temperature. -
Page 16: Multi-Deck Shelf Alignment
TART UP Glass Front Return Air Path (keep clear) Package Guard MULTI-DECK SHELF ALIGNMENT Taped to one of the shelves in each merchandiser is a small plastic bag containing shelf alignment strips. These strips are designed to enhance the appearance of the shelves by aligning the front edge of each shelf with that of an adjacent shelf. -
Page 17: Maintenance
Allow glass fronts, ends and service doors to warm before applying hot water.. HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) MAINTENANCE • Remove the product and all loose debris to avoid clogging the waste outlet. -
Page 18: Cleaning Under Merchandiser
AINTENANCE CLEANING UNDER MERCHANDISERS Remove splashguards not sealed to floor. Use a vacuum with a long wand attachment to remove accumulated dust and debris from under the mer- chandiser. REMOVING SCRATCHES FROM BUMPER Most scratches and dings can be removed using the following procedure. -
Page 19: Service
Assembly Chain Power Cord Hook Bushing HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) SERVICE Always disconnect the electrical power at the main disconnect when servicing or replacing any electrical component. This includes, but is not limited to, such items as fans, heaters, thermostats and lights. - Page 20 6 screws. Reconnect fan motor to wiring harness. Turn on power. 10. Verify that fan motor is working and fan blade is turning in the correct direction. Make sure fan blade spins freely. F2XLG Reheat Heater Anti-Sweat Heater Electric Defrost Thermostat...
-
Page 21: Replacing Ambient Muffin Fan Assembly
Make sure fan blade spins freely. 9. Replace access panel. Restore power. Muffin Fan Assembly HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) WARNING Always disconnect the electrical power at the main disconnect when servicing or replacing any electrical component. This includes, but is not limited to, such items as fans, heaters, thermostats and lights. -
Page 22: Replacing Reheat Heaters
ERVICE REPLACING REHEAT HEATERS For access to these heaters: 1. Turn off power. 2. Remove shelves, wire racks, bottom display pans and back panels. 3. Disconnect heater from wiring harness. 4. Remove screws and clips holding heater in position. Be sure to save the attachment clips for the new heater. -
Page 23: Replacing Modular Electric Defrost Heater
11. Verify that new heater is working properly. 12. Replace back panel, display pans, wire racks and shelves. HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) WARNING Always disconnect the electrical power at the main disconnect when servicing or replacing any electrical component. -
Page 24: Replacing Anti-Sweat Heater
ERVICE REPLACING ANTI-SWEAT HEATER For access to these heaters: 1. Turn off power. 2. Remove shelves. 3. Remove screws holding honeycomb assembly. 4. Pivot honeycomb assembly down; remove honeycomb. 5. Disconnect heater from wiring harness. 6. Remove adhesive-backed heater. 7. Clean surface before applying new adhesive- backed heater. -
Page 25: Replacing Multi-Glass Assembly With Anti-Sweat Heater
Cross Section View (without Channel Assembly) Refer to photographs on next page. HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) Always disconnect the electrical power at the main disconnect when servicing or replacing any electrical component. This includes, but is not limited to, such items as fans, heaters, thermostats and lights. -
Page 26: Replacing Electronic Ballasts
ERVICE Left End Screw Locations Feed Wire Through Bushing (Return Grille Removed) Detail Shows Wiring in Place, with Return Grille Installed. P/N 424382A REPLACING ELECTRONIC BALLASTS Canopy Ballasts These ballast are located at the top of the merchandiser inside the canopy. The switch in the canopy operates the canopy lamps. -
Page 27: Replacing Lamp Holders And End Caps
Hussmann lamp holders and end caps. Use of non-Hussmann parts may result in poor electrical contact and short lamp life. HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 (Printed in U.S.A.) REPLACING DAMAGED DRAIN FITTING The following procedure is for the field repair of a broken drain fitting. -
Page 28: Repairing Aluminum Coils
6-10 ERVICE REPAIRING ALUMINUM COIL The aluminum coils used in Hussmann merchan- disers may be easily repaired in the field. Materials are available from local refrigeration wholesalers. Hussmann recommends the following solders and technique: Solders Aladdin Welding Products Inc. P.O. Box 7188 1300 Burton St. - Page 29 The full product warranty is available from our website, www.hussmann.com To obtain additional information or other support, contact your Hussmann representative. Please include the model and serial number of the product. Hussmann Corporation, Corporate Headquarters: Bridgeton, Missouri, U.S.A. 63044-2483 01 July 2005...
