Switch Installation
Read the topics and perform the procedures in this order:
Warnings
These warnings are translated into several languages in the Regulatory Compliance and Safety
Information for the Cisco ME 3400E Ethernet Access Switches document that ships with the switch.
These warning statements apply to all the switches:
Warning
Before working on equipment that is connected to power lines, remove jewelry (including rings,
necklaces, and watches). Metal objects will heat up when connected to power and ground and can
cause serious burns or weld the metal object to the terminals. Statement 43
Do not stack the chassis on any other equipment. If the chassis falls, it can cause severe bodily injury
Warning
and equipment damage. Statement 48
OL-16447-01
Warnings, page 2-1
Installation Guidelines, page 2-4
Verifying Switch Operation, page 2-5
Installing the Switch, page 2-5
Installing and Removing SFP Modules, page 2-19
Inserting and Removing the SFP Module Patch Cable, page 2-21
Connecting to the 10/100 and 10/100/1000 Ports, page 2-22
Connecting to Fiber-Optic SFP Modules, page 2-24
Connecting to 1000BASE-T SFP Modules, page 2-25
Connecting to Dual-Purpose Ports, page 2-26
Where to Go Next, page 2-26
C H A P T E R
Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide
2
2-1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ME 3400E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cisco ME 3400E

  • Page 1 • Warnings These warnings are translated into several languages in the Regulatory Compliance and Safety Information for the Cisco ME 3400E Ethernet Access Switches document that ships with the switch. These warning statements apply to all the switches: Warning Before working on equipment that is connected to power lines, remove jewelry (including rings, necklaces, and watches).
  • Page 2 This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security. Statement 1017 Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide OL-16447-01...
  • Page 3 Note The grounding architecture of this product is DC-isolated (DC-I). You can use the grounding lug to attach a wrist strap for ESD protection during servicing. Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide OL-16447-01...
  • Page 4 Chapter 2 Switch Installation Installation Guidelines These warning statements apply to the Cisco ME 3400E-24TS-M and the Cisco ME 3400EG-12CS-M: To prevent the system from overheating, do not operate it in an area that exceeds the maximum Warning recommended ambient temperature of: 149°F (65°C) Statement 1047...
  • Page 5 “Installing and Removing AC- and DC-Power-Supply Modules.” • To power on the Cisco ME 3400EG-2CS-A, connect one end of the AC- power cord to the AC-power connector on the switch, and connect the other end of the power cord to an AC-power outlet. (See Figure 2-1.)
  • Page 6 Installing the switch in a 24-inch rack requires an optional bracket kit that is not included with the switch. You can order a kit containing the 24-inch rack-mounting brackets and hardware from Cisco. The kit part number is RCKMNT-1RU= (700-12398-XX).
  • Page 7 For 23-inch racks, use part number RCKMNT-23IN-1RU (700-21646-XX) on all except the Cisco ME 33400EG-2CS-A, and see Figure 2-6 on page 2-10. For the Cisco ME 3400EG-2CS-A, use RCKMNT-23-CMPCT= (700-23402-01). Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide OL-16447-01...
  • Page 8 For ETSI racks, use part number RCKMNT-ETSI-1RU= (700-19781-XX), and see Figure 2-8 on page 2-12. The Cisco ME 3400EG-2CS-A does not support the ETSI racks. Attaching Brackets for 19-Inch Racks Figure 2-4 shows how to attach brackets for 19-inch racks on all switches except the Cisco ME 3400EG-2CS-A.
  • Page 9 Chapter 2 Switch Installation Installing the Switch Attaching Brackets on Cisco ME 3400EG-2CS-A for 19-Inch, 23-Inch, and 24-Inch Racks Figure 2-5 shows how to use the tab on the bracket and the Phillips flat-head screw to attach the short side of each bracket to the switch.
  • Page 10 23-inch racks on all switches except the Cisco ME 3400EG-2CS-A. Figure 2-6 Attaching Brackets for 23-Inch Racks Phillips flat-head screws Rear-mounting position Front-mounting position Mid-mounting position Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-10 OL-16447-01...
  • Page 11 24-inch racks on all switches except the Cisco ME 3400EG-2CS-A. Figure 2-7 Attaching Brackets for 24-Inch Racks Phillips flat-head screws Rear-mounting position Front-mounting position Mid-mounting position Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-11 OL-16447-01...
  • Page 12 ETSI racks on all switches except the Cisco ME 3400EG-2CS-A. Figure 2-8 Attaching Brackets for ETSI Racks Phillips flat-head screws Rear-mounting position Front-mounting position Mid-mounting position Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-12 OL-16447-01...
  • Page 13 Mounting in a Rack Phillips machine screws Cable guide and screw Figure 2-10 Mounting Cisco ME 3400EG-2CS-A in a Rack Black Phillips machine screw Number-10 Phillips truss-head screws Cable guide Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-13 OL-16447-01...
  • Page 14 Connect to the RJ-45 connector of a dual-purpose port, and run the initial configuration dialog. • See the Cisco ME 3400E Ethernet Access Switch Getting Started Guide for instructions. Connect to the front-panel ports. See the “Connecting to the 10/100 and 10/100/1000 Ports” section •...
  • Page 15 Read the wall-mounting instructions carefully before beginning installation. Failure to use the Warning correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system. Statement 378 Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-15 OL-16447-01...
  • Page 16 Switch Installation Installing the Switch Cisco ME 3400EG-12CS-M Mount the switch with the front panel facing down (Figure 2-13). Figure 2-13 Mounting Cisco ME 3400EG-12CS-M on a Wall User-supplied screws Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-16 OL-16447-01...
  • Page 17 Switch Installation Installing the Switch Cisco ME 3400E-24TS-M Mount the switch with the side panel facing up (Figure 2-14). Figure 2-14 Mounting Cisco ME 3400E-24TS-M on a Wall User-supplied screws Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-17 OL-16447-01...
  • Page 18 Connect to a 10/100 port or to the RJ-45 connector of a dual-purpose port, and run the initial • configuration dialog. See the Cisco ME 3400E Ethernet Access Switch Getting Started Guide for instructions. Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide...
  • Page 19 Connect to a 10/100 port or to the RJ-45 connector of a dual-purpose port, and run the initial • configuration dialog. See the Cisco ME 3400E Ethernet Access Switch Getting Started Guide for instructions. Connect to the front-panel ports. See the “Connecting to the 10/100 and 10/100/1000 Ports”...
  • Page 20 For copper 1000BASE-T SFP modules, insert the RJ-45 cable connector into the SFP module. • When connecting to 1000BASE-T SFP modules, be sure to use a twisted four-pair, Category 5 or Note higher cable. Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-20 OL-16447-01...
  • Page 21 Insert the SFP module patch cable into the slot until you feel the connector on the cable snap into place Step 2 in the rear of the slot (see Figure 2-19). Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-21 OL-16447-01...
  • Page 22 To maximize performance, choose one of these methods for configuring the Ethernet ports: Let the ports autonegotiate both speed and duplex. • Set the port speed and duplex parameters on both ends of the connection. • Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-22 OL-16447-01...
  • Page 23 STP is not supported. Reconfigure and reboot the connected device, if necessary. Step 3 Repeat Steps 1 through 3 to connect each device. Step 4 Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-23 OL-16447-01...
  • Page 24 See Chapter 4, “Troubleshooting,” solutions to cabling problems. If necessary, reconfigure and restart the switch or target device. Step 5 Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-24 OL-16447-01...
  • Page 25 See Chapter 4, “Troubleshooting,” solutions to cabling problems. Step 4 If necessary, reconfigure and restart the switch or target device. Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-25 OL-16447-01...
  • Page 26 Where to Go Next You can use the default configuration or use any of the management options described in the “Management Options” section on page 1-14 to change the switch settings. Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide 2-26 OL-16447-01...
