  • Page 1 Razor Assembly Guide Razor Assembly Guide (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 2 Razor Assembly Guide Introduction All Orion Robotics brackets are made in the USA. We fabricate them using a large in-house industrial laser. We anodized our brackets to prevent oxidation. This gives the bracket a much better look and longer life.
  • Page 3 STEP M3X8 Flathead M3LW (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 4 STEP M3X6 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 5 STEP BEARING (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 6 STEP (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 7 STEP E-CLIP (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 8 STEP M4X8 M4LW (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 9 STEP BEARING (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 10 STEP E-CLIP (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 11 STEP M3X8 M3LW (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 12 STEP 10 M3X12 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 13 STEP 11 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 14 STEP 12 M3X8 M3LW (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 15 STEP 13 M3X8 Flathead M3LW (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 16 STEP 14 M3X6 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 17 STEP 15 BEARING (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 18 STEP 16 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 19 STEP 17 E-CLIP (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 20 STEP 18 M4X8 M4LW (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 21 STEP 19 BEARING (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 22 STEP E-CLIP (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 23 STEP 20 M3X8 M3LW (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 24 STEP 21 M3X12 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 25 STEP 22 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 26 STEP 23 M3X8 M3LW (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 27 STEP 24 30MM M3X8 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 28 STEP 25 M2.5X6 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 29 STEP 26 M2.5X6 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 30 STEP 27 M3X8 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 31 STEP 28 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 32 STEP 29 M3X8 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 33 STEP 30 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 34 STEP 31 M3X8 20MM M3X8 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 35 STEP 32 M3X8 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 36 STEP 33 M2.5X6 M2.5X6 M2.5X6 M2.5X6 (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 37 STEP 34 (c) 2012 Orion Robotics. All Rights Reserved.

  • Page 38: Assembly Guide

    The following tables defines each PS2 controller button function in the default Arduino program. PS2 Button Function Notes Right Joystick Up Forward Right Joystick Down Reverse Right Joystick Left Turn Left Right Joystick Right Turn Right Select Activate/Deactivate (c) 2012 Orion Robotics. All Rights Reserved.
  • Page 39 Wiring Table From Battery + Battery - Right Motor + Roboclaw M1+ Right Motor - Roboclaw M1- Left Motor + Roboclaw M2+ Left Motor - Roboclaw M2- Roboclaw S1 Roboclaw S2 PS2 Controller (c) 2012 Orion Robotics. All Rights Reserved.

  • Page 40: Warranty

    Orion Robotics warranties its products against defects in material and workmanship for a period of 90 days. If a defect is discovered, Orion Robotics will, at our discretion, repair, replace, or refund the purchase price of the product in question. Contact us at support@orionrobotics.com. No returns will be accepted without the proper authorization.
