The following figure illustrates the location of the different ports at the rear of your scanner
(SnapScan e42/e52).

Changing the Handle

It is possible to customize your SnapScan by changing its handle.
1 Press the two clips at the inside of the cover upwards and lift the handle.
1 2 3
1. USB Port (labeled with the USB icon ) to
make a connection to your computer
2. Transparency Module Port (SnapScan e52
only)
3. Power connector
Chapter 1: Preparing the Scanner 12
