innoflame
FIREPLACE OPERATING MANUAL
The actual appearance should be subject to the purchase model
Thank you
Thank you and congratulations on your
purchase of our fireplace. Please read the
Installation instructions carefully before
using this fireplace.
CONSUMER SAFETY INFORMATION: PLEASE READ THIS MANUAL BEFORE
INSTALLING AND OPERATING THIS FIREPLACE. FAILURE TO FOLLOW
THESE INSTRUCTIONS MAY RESULT IN A POSSIBLE ELECTRIC SHOCK, FIRE
HAZARD , AND/OR INJURY AND WILL VOID THE WARRANTY.
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED, AN
ELECTRIC SHOCK OR FIRE MAY RESULT IN PROPERTY DAMAGE, PERSON-
AL INJURY, OR LOSS OF LIFE.
MODELS:
RV23D80L-1
RV26D80L-1
RV30D80S-1
RV48D80L-1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for INNOFLAME RV23D80L-1
Summary of Contents for INNOFLAME RV23D80L-1
- Page 1 FIREPLACE OPERATING MANUAL The actual appearance should be subject to the purchase model Thank you MODELS: RV23D80L-1 Thank you and congratulations on your RV26D80L-1 purchase of our fireplace. Please read the RV30D80S-1 Installation instructions carefully before using this fireplace.
-
Page 2: Important Instructions
IMPORTANT INSTRUCTIONS When using fireplace, basic precautions should always be followed to reduce the risk of fire, electri- cal shock, and/or injury including the following: 1. Read all instructions before using this fireplace. 2. This fireplace is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provid- ed, use handles when moving this fireplace. -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS Cabinet Dimensions Fireplace Dimensions Model NO. Model NO. RV23D80L-1 22.3” 6.2” 18.3” RV23D80L-1 21.9” 4.7” 18.1” RV26D80L-1 25.5” 6.2” 18.3” RV26D80L-1 25.1” 4.7” 18.1” RV30D80S-1 29.7” 6.2” 14.9” RV30D80S-1 29.2” 4.7” 14.7” RV48D80L-1 4.7” 18.1” 41.5” 6.2” 18.3”... - Page 4 WARNING: Cabinet construction and electrical outlet wiring must comply with local bulding codes regulations to reduce the risk of fire, electrical shock and injury to persons. 2. Use 8 supplied screws to secure the 1. Plug into the power supply and push the fireplace to cabinet.
-
Page 5: Control Panel
OPERATING INSTRUCTIONS CONTROL PANEL Control panel can be access at upper-right corner of the fireplace. NOTE: The remote control is intended only for the functional operation of the product, It can not lock/unlock the heating function！ The Power Button The power button turns the fireplace on & off. When the fireplace is off pressing the power button once will switch on the fireplace. -
Page 6: Battery Replacement
The Timer Button The TIMER has adjustable setting with range from 30 minutes to 6 hours and OFF. As shown the following: 30 minutes- 1h-2h-3h-4h-5h-6h-OFF. Once you have set the timer, and the timer is up, the ember bed will flash 6 timers and close all the functions and enter standby mode. In this mode, you should touch the power icon to restart the fireplace. -
Page 7: Care And Maintenance
CARE AND MAINTENANCE IMPORTANT: ▪ Always unplug the power cord before cleaning the fireplace. Allow the unit to cool before cleaning it. ▪ Wipe the exterior surface of the fireplace occasionally with a soft, damp cloth (not dripping wet), and dry the exterior surface before operating. ▪... -
Page 8: Circuit Diagram
CIRCUIT DIAGRAM RV23D80L-1 & RV26D80L-1 & RV30D80S-1 CIRCUIT DIAGRAM RV48D80L-1 CIRCUIT DIAGRAM Made in China Printed in China...
Need help?
Do you have a question about the RV23D80L-1 and is the answer not in the manual?
Questions and answers
In the morning I hit the remote p0wer on button The heat starts then goes off after just a few minutes. How do I correct this
If your INNOFLAME RV23D80L-1 heater turns off after a few minutes when you press the power button, check if the timer function is set. The timer can be adjusted from 30 minutes to 6 hours or turned off. If the timer is active, the fireplace will shut down when the set time expires.
To resolve this:
1. Press the Timer Button to check the current setting.
2. Adjust the timer to a longer duration or turn it off.
If the issue persists, ensure the heater function is not locked. To unlock:
1. Press and hold the Heater Button for 10 seconds until the ember bed flashes 6 times.
If the problem continues, check for overheating or power supply issues.
