- Page 1 UN-33-SS-Straight Instruction Manual ELECTRIC SIT-STAND DESK PLEASE CALL US AT 888-993-3757 IF ANY ASSISTANCE...
-
Page 2: Electrical Safety Instructions
Preface Electrical Safety Instructions: CAUTION This electric height adjustable standing desk consists of a heavy-duty steel desk frame and a motorized height The product is powered by electricity. In order to avoid burns, fire and electric shock, please read the instructions carefully. adjustment system. - Page 3 Preparation Checklist and Installation What are the specifications you need to know? Weight Capacity Power Input Operation Temperature 125kg (275lbs) (100~240V) °C 40°C A (x1) B (x2) C (x2) D (x2) Crossbar Side Bracket Foot Lifting Column What are the tools you require while installation? Bubble Level Allen Wrench...
- Page 4 Attaching Side Brackets S-A (x8) S-B (x8) S-C (x10) Hex Head Screw Hex Head Screw Phillips Head Screw+ 1 Spacer Shipping S-D (x2) S-E (x2) S-F (x4) Blanket Phillips Head Screw Phillips Head Screw Phillips Head Screw S-G (x3) S-H (x10) S-I (x1) Cable Clip Anti-Vibration Pad...
-
Page 5: Adjusting The Frame
Adjusting the Frame • Ensure that the frame is placed in the center of the table. • Then adjust the frame to suit the size of the tabletop. 35(max) 0(min) 35(max) Loosen the hex head screws that fix the When adjusting the frame position, please make sure it doesn't exceed the range of silk screen printing on the inner crossbar. adjustable junction, but don't completely take out the screws. - Page 6 Drilling Mounting Holes Use a drill to make mounting holes on the backside of the tabletop through the 8 mounting holes on the side brackets. Note: The depth of the mounting holes should be over 10mm and the diameter should be less than 3mm. Drill Retighten all the hex head screws to finish the adjustment.
- Page 7 Assembling the Lifting Columns Assembling the Feet • Insert one lifting column into one end of the crossbar with • Place the foot on the bottom of the lifting column. Align the the head of the lifting column facing inward. Make sure the mounting holes on the foot with the screw holes on the mounting holes on the lifting column completely align with lifting column.
- Page 8 Assembling the Fixing Plate Attaching the Control Box • Align the mounting holes on the fixing plate with the screw holes as shown. • Turn over the desk frame with the crossbar facing up. • Attach the fixing plate on the center of the crossbar with 2 screws using a Phillips screwdriver.
- Page 9 Assembling the Cable Management Tray • The arrow on the fixing plate indicates the direction of sliding in the control box. Follow the direction of the arrow to mount the control box. • Slide the control box to the center of fixing plate. •...
- Page 10 Assembling the Desktop Attach the anti-vibration pads to the surface of the crossbar on the ten positions as shown. Tighten the knobs on the tray hangers.
- Page 11 • Align the previously drilled screw holes with • Attach the controller to the desktop with 2 screws using a driller. the mounting holes on the crossbar. Insert • Stick the adhesive cable clip under desk to organize cords. and tighten the 4 screws from below.
-
Page 12: Level Adjustment
Level Adjustment Height Adjustment There are two adjustable foot pads under each foot. If the floor isn't even, simply turn the pad to adjust the level to make the desk stable. Connect the desk to power. Tip: Use a bubble level to check if the desktop is even. You can now use the sit-stand desk.
