- Page 1 Cubicle System Installation Guide 888-993-3757 skutchi.com...
-
Page 2: Tools Needed
slim Tools Needed Cubicle System 1/4 Driver Identifying Parts 2 Way 3 Way 4 Way End Trim 120 Degree 120 Degree 3 Way 2 Way Box Leg C Leg Square Column Feet without Casters Feet with Casters Sit-Stand Base Right Cantilver Left Cantilver Double Cantilver Corner Worksurface... - Page 3 slim Connecting Panels Cubicle System Ex. of hook on panel End trim Panel Hooks 1C-2. End trim Install: To insert end trim, lift up top cap (see below) then slide end trim into slot with ridges facing outward. Top Cap End trim *No tools are required to lock SAPslim panels together.
- Page 4 slim Installing Panels on a Connector Cubicle System 2 way connector Connect the panels to the connector first and then attach second set of panels. These attach the same way as attaching 2 panels togeth- er (reference figure 1A.). End trim: Flip up the top cap and slide plastic end trim in place.
- Page 5 slim Attaching Hinges Cubicle System Hinge Assembly 1. Attach hinges to panels. 2. Insert rod into black cover. 3. Insert rod and cover into hinge that is angled north on the first panel. 1. Once you attach the hinges on one panel, be sure to attach the hinges the opposite way on the second panel so one is angled north and the other is angled south(...
- Page 6 slim Installing Feet Support Cubicle System *If using feet on panels attach them before attaching the panels together. Panel with feet (castors) Panel with feet *Note: If attaching 2 or more panels together use only one foot between two panels. (see below). *When using hinges on connecting panels a wheel can be added to one of the panels in...
