950P Portable Air Cleaning System

System Overview

COMPONENT DESCRIPTION

The 950P Portable DFS Air Cleaning System integrates the system components into a single, portable unit:
the Prefilter, V-Bank Main Filter and the High Energy Grid are accessible from the back service door. The unit
is also remotely controllable by using a remote control. The fan inlet screen is located on the bottom side of
the unit and provides protection from loose items being drawn into the fan and thus damaging the unit
the internal components.
Electrical controls are located on the front of the unit. It consists of the Main Power ON-OFF switch with a
Blue LED to indicate HVPS power status, Blower Speed Status and Blower Speed Control Switch.
Replacement Filters
Prefilter MERV-8 (30% Efficiency)
Formaldehyde > 99%
VOC Post Filter
DFS V-Bank
Main Filter (down to .007 microns)
*Replacement period depends on the level of pollution in the environment
#10065
Efficiency Replacement Period*
1-2 times per year
1/2" Filter: 2 times per year
Benzine > 99%
Optional V-Bank: once a year
Toluene > 99%
99.99% Efficient
once a year
12

Installation Procedures

POWER REQUIREMENT
The power requirements are as follows:
*Electrical disconnects may also be required - check local electrical codes
and

LOCATION DETERMINATION

The 950P is designed as a portable floor model. Place the air purifier anywhere in the room; being careful
not to block air from "entering" the intake grill, or "exiting" the top grill cover.
Do not place the air purifier where drapes or other objects block airflow.
For best performance, it is recommended to place the air purifier at least two (2) feet from walls and
other obstructions.
Place the unit on a flat and level surface to allow continuous airflow to the bottom intake and out the top
outlet grill.
Do not run power cord under carpeting or near heaters, registers, radiators, stoves or fireplaces. To avoid a
tripping hazard, keep the power cord away from traffic areas.
Never operate the air purifier in areas where combustible gases or vapors are present or any other
flammable materials.
©Intellipure 2015 #10065
950P Portable Air Cleaning System
Model Power
V Hz Phase
950P 120 50/60 1
950P 220 50/60 1
The filter unit will not turn on without the Prefilter installed and firmly seated.
Do not operate unit using an extension cord.
13
FLA Power Usage
Max Start-up
AMPS WATTS
4.44
590
2.21 560
