- Page 1 Operation Manual Intellipure 950P COMMERCIAL PORTABLE AIR PURIFICATION SYSTEM...
-
Page 3: Table Of Contents
V-Bank Main Filter Replacement Cleaning the Unit Parts List Voltage Adjustments ......13 Troubleshooting ........14 System Schematic .........15 Part Number: #10065IN Copyright: © 2020 All rights reserved. Address: Intellipure, Inc. 3420 Maple Ave. Pulaski, NY 13142 Phone No: 315-298-2904 1-800-843-3860 Email: info@intellipure.com... -
Page 4: Limited Warranty
Intellipure authorized technician. The sole responsibility of Intellipure under this Limited Warranty is, at its sole discretion, to either repair or replace a duly registered product (or defective part thereof) with the same comparable model within a reasonable period of time, subject to the following exclusions, limitations, statutory rights, and warranty claim procedures. -
Page 5: Safety Precautions
When a freight carrier signs the Intellipure bill of lading, the carrier accepts the responsibility for any subsequent shortages or damage evident or concealed. Inspection by the carrier of damage evident or concealed must be requested. -
Page 6: System Overview
98 kg COMPONENT DESCRIPTION The 950P Portable DFS Air Cleaning System integrates the system components into a single, portable unit: the Prefilter, V-Bank Main Filter and the High Energy Grid are accessible from the filter access door. Electrical controls are located on the front of the unit. It consists of the Main Power ON-OFF switch with a Blue LED to indicate High Voltage Power Supply power status, Blower Speed Status and Blower Speed Control Switch. -
Page 7: Installation Procedures
1.71 LOCATION DETERMINATION The 950P is designed as a portable floor model, the location and operation of the unit shall follow state /local code for installation of electrical devices. Place the air purifier anywhere in the room and on a flat and level surface to allow continuous airflow to the bottom intake and out the top outlet grill. -
Page 8: System Operation
30 seconds after turning the unit off before opening the Filter Access Door. The touch control technology is designed to operate under minimal pressure. Lightly touch or slide over the buttons for an optimal user experience. Intellipure © 2021 All rights reserved. - Page 9 Intellipure 950P System Operation POWER ON / OFF When unit is plugged in, control goes through self-diagnosis and then returns to the last setting before power was lost. When unit is off (and plugged in), only the power button is dimly lit.
-
Page 10: Maintenance
Maintenance When replacing filters use only Intellipure certified filters. Intellipure filters are designed for high voltage operation. Use of non-Intellipure filters can be hazardous to personnel and equipment voiding the warranty. PREFILTER REPLACEMENT Lock the (2) front wheels to secure the unit. (fig-1) Remove the filter access door by unlocking four quarter turn latches. -
Page 11: V-Bank Main Filter Replacement
Intellipure 950P Maintenance Always unplug the unit and wait a minimum of 30 seconds before touching the unit. V-BANK MAIN FILTER REPLACEMENT - Lock the (2) front wheels to secure the unit. (fig-1 on page 10) - Remove the filter access door by unlocking four quarter turn latches (fig-2 on page 10). -
Page 12: Cleaning The Unit
Do not install the High Energy Grid to the V Bank Filter until wires are completely dry. Do not install the High Energy Grid to the V Bank Filter until wires are completely dry. Intellipure © 2021 All rights reserved. -
Page 13: Parts List
Intellipure 950P Maintenance PARTS LIST Order all parts by contacting: Phone No: 315-298-2904 • 1-800-843-3860 Fax No: 315-298-6992 Email: info@intellipure.com Description Part Number Prefilter FT-101-2 V-Bank Main Filter 950/1200_MainFilter High Energy Grid 950/1200_HEGrid Multiplier NZ-025 Blower EC-026 120v Power Supply... -
Page 14: Troubleshooting
Troubleshooting For additional troubleshooting assistance contact Intellipure; Monday-Friday, 8am-5pm EST: Phone No: 315-298-2904 • 1-800-843-3860 Fax No: 315-298-6992 Email: info@intellipure.com Service should only be done by a qualified factory trained technician. Problem Description Recommended Action Ensure power cord is plugged in, electrical outlet is energized. -
Page 15: System Schematic
Intellipure 950P Troubleshooting Problem Description Recommended Action 4. Pre-filter indicator is out and Change Pre-filter needs to be replaced. (Page 13 part number) pre-filter indicator is illuminated in red 5. Main filter indicator is out. Change main filter Main filter needs to be replaced. (Page 13 part number) indicator is illuminated in red 6. - Page 16 intellipure.com...
