Summary of Contents for DatoHome L-B200
- Page 1 User manual...
- Page 2 Preparing for Installation ..............................2 Door Lock Installation ..............................4 Lock Settings ..................................9 Troubleshooting ................................11 Specifications ..................................12 Especificaciones ................................12 Preparativos para la instalación ........................... 13 Instalación de la cerradura ............................15 Configuración de la cerradura ............................19 Solución de errores .................................
- Page 3 1 Checking the delivery set Key hole cover User manual Exterior handle Interior handle Rubber pads User manual Strike parts Latch Keys & Key hole Spindle Connecting Mounting Screws for strike cover pin screws x2 screws x2 plate x4 2 Installation tools a M4 Phillips screwdriver if mounting holes are ready.
- Page 4 3 Inspection of door specifications ＂ ＂ ２ a. Door Thickness: (30~53mm). ～ " " b. Door lock mounting hole diameter range (single round hole): 2.17 c. Distance from the center of the lock mounting hole to the door profile ( "...
- Page 5 1 Latch Bolt Installation a. Adjust the Latch bolt according to the distance between the center of the keyhole and the edge of the door (make sure the latch basket is in place of " " b. Determine the orientation of the latch bolt plane according to the door opening direction. (Refer to Article 3-d of Chapter ﹃Preparing for installation﹄).
- Page 6 2 Handle adjustment a. The default setting is right handle， if your door is left handle door please adjust the limit plate to the position limiting the handle lifting. b. Install the spindle to the exterior handle， insert the pin to fix the spindle on the the exterior handle， bend the ends of pin to prevent disengagement，...
- Page 7 4: Mount the connecting screws on the 3: Install the batteries into the exterior handle exterior handle Note: No need to install batteries in the interior handle. Round end Planed end only the outside handle (the one with the fingerprint reader) needs batteries. 5: Pass the exterior (outside) handle with spindle 6: Testing the fundamental functions and screws through the latch bolt.
- Page 8 7 Finishing the Installation a. Insert the interior handle from the other side of the door by aligning the quad slot with the spindle (remember to insert the rubber pad in advance). b. Tighten and secure the rear handle with two mounting screws into the screw holes of the connecting screws coming from the front handle.
- Page 9 1 Adding fingerprints a. Activate the 'settings'-mode by rotating the mechanical key clockwise about 15-20 degrees for about 3 seconds. Applying pressure until the blue indicator lights on， then releasing after 1 beep， the fingerprint scanner is ready. Hold for 3 seconds b.
- Page 10 2 Remove fingerprints a. Activate the 'setting'-mode by rotating the mechanical key clockwise about 15-20 degrees. b. Hold for about 5 seconds until a red indicator light flashes. c. Release the mechanical key. All fingerprints will be removed after a long beep (restore factory default)， and ANY fingerprint can now open the door.
- Page 11 Q: No action or abnormal action found after the installation of lock. A: Check the battery installation direction and battery poles for correct position. The battery cover may not be covered properly. Q: What to do if the battery is dead? A: Open the lock by key and replace the battery timely (Please keep the mechanical key safe).
- Page 12 Q: After setting the fingerprint, anyone who is not authorized can open the lock by using any fingerprints. A: Likely the initial fingerprint recording failed. Please refer to the instruction book to do fingerprint record again (in the article 1 of chapter 4 ﹃Lock settings﹄). Q: What if I lose my key? A: Immediately replace your lock with a new one.
- Page 13 Semiconductor fingerprint sensor with a resolution of 508DPI； capable of Fingerprint Sensor 360° fingerprint identification and live fingerprint identification Sensor semiconductor de Huella digital con una resolución de 508DPI； con Sensor de Huella Digital capacidad de identificación de 360º de huellas digital vivas Number of Fingerprints Up to 40 fingerprints to store and each fingerprint shall be recorded for 5 times Almacena hasta 40 huellas digitales y cada huella deberá...
