James Walker KlickFix Installation Manual

Installation Guide for
James Walker KlickFix
Your James Walker KlickFix is
factory-assembled ready for
installation.
Gland
Gasket
®
Note: there are four options for the pump
shaft sleeve that must be taken into
sequence.
Shaft sleeve supplied with the
1a.
or sleeve of pump.
1b. New shaft sleeve supplied to replace
existing shaft sleeve.
1c . Existing shaft sleeve supplied with
new coating applied by James Walker.
1d . No shaft sleeve supplied with KlickFix;
either because existing sleeve on pump
shaft meets James Walker criteria, or
customer has manufactured own sleeve.
Radial Slot
for deployment
KlickFix is factory assembled.
EN
KlickFix ist werkseitig montiert.
DE
KlickFix viene assemblato in
IT
fabbrica ..
KlickFix wordt geheel.
NL
geassembleerd geleverd.
KlickFix viene montado de fábrica.
ES
Le KlickFix est assemblé en usine.
F

Deployment Sleeve Flange

P ositioning Clip
Position Control Pin
Rear
Centralising
Bush
.
.
.
Shaft Sleeve
Set Screw
