James Walker KlickFix Installation And Operating Manual

Installation and Operating Guide for
KlickFix
®
Your James Walker KlickFix
is factory-assembled ready
for installation.
Please read these instructions before starting to fit the seal
Note: there are four options for the pump
shaft sleeve that must be taken into account
when following the fitting sequence.
1a. Shaft sleeve supplied with the cartridge
to fit directly on the existing shaft or
sleeve of pump.
1b. New shaft sleeve supplied to replace
existing shaft sleeve.
1c. Existing shaft sleeve supplied with
new coating applied by James Walker.
1d. No shaft sleeve supplied with KlickFix;
either because existing sleeve on pump
shaft meets James Walker criteria, or
customer has manufactured own sleeve.
Continuous Groove for Deployment
KlickFix is factory assembled.
EN
KlickFix ist werkseitig montiert.
DE
KlickFix viene assemblato in
IT
fabbrica.
NL KlickFix wordt geheel.
geassembleerd geleverd.
KlickFix viene montado de fábrica.
ES
Le KlickFix est assemblé en usine.
F
Deployment Sleeve Flange
E-Clips
Guide Pin
Outer
Centralising
Bush
