James Walker Teesele Fittings Manual

Double-acting dynamic seal for high pressure equipment

Download this manual

Fitting Guide for

Teesele —

double-acting dynamic seal for high pressure equipment

Teesele

Teesele elastomeric element

Anti-extrusion ring

Teesele

Teesele elastomeric element

Anti-extrusion ring

internal seal

external seal

Please read these instructions fully

before starting to fit the seal.

Check that all components of the seal

are present.

Each set comprises:

1 off elastomeric sealing element

(either for internal seal or external

seal).

2 off scarf-split plastic anti-extrusion

rings (either for internal seal or

external seal).

Check that you have all the seal

components

Need help?

Do you have a question about the Teesele and is the answer not in the manual?

Page 1 1 off elastomeric sealing element (either for internal seal or external seal). 2 off scarf-split plastic anti-extrusion rings (either for internal seal or external seal). ® Teesele elastomeric element Check that you have all the seal Anti-extrusion ring components Anti-extrusion ring ® Teesele external seal ®...
Page 2 ® Teesele — double-acting dynamic seal for high pressure equipment ® Ensure that the Teesele is the correct Check seal type, size & condition size and type for the housing. Inspect all seal components to ensure they are in good condition and have not been damaged during storage.
Page 3 Align the rod carefully, and insert it until it seal bore. just touches the seal, then press the rod ® firmly through the seal bore. The Teesele is now installed. A thin film of system compatible lubricant may be used (if in...
Page 4 Statements of operating limits quoted in this publication are not an indication that these values can be applied simultaneously. To ensure you are working with the very latest product specifications, please consult the relevant section of the James Walker website: www.jameswalker.biz.
