Turning Off The Appliance In The Event Of Faults; Care And Maintenance - Italinox DMG007 Installation, Operation And Maintenance Manual

2.1 TURNING OFF THE APPLIANCE
At the end of day the device must be turned off from the
button "A". The light "B" will be off which indicates the power
is off. These steps been fulfilled after the water is emptied in
the device. This process is carried out by the user, by pulling
the waster plug out (See FigureB). (On drain pump models "F"
button to be pushed which turns the drain pump on. This
process is followed with the eye. Waste plug must be pulled
out either on drain pump models or gravity drain models). Do
not put the waste plug on its place until the water is
completely drained. Replace the plug after observing, and
definitely make sure that the plug is fitted its place. If the
appliance is not going to be used for long term, cut off the
machine's electricity. Suction filter should be checked each
day before using the machine. Remove it by turning clockwise
and clean under water. Make sure to put the suction filter
back before running the machine.
(FIGURE B)
TURNING OFF THE APLLIANCE IN
4.
THE EVENT OF FAULTS
In the event of faults, switch off the appliance as follows:
● Disconnect the appliance from the main power supply at
the isolating switch and close the water cocks.
● Contact a technical service centre with personel trained
and authorised by the manufacturer.

CARE AND MAINTENANCE

5.
● Disconnect the appliance from the main power supply at
isolating switch and close the water cocks.
● Do not wash the appliance with jets of water.
● Do not use products containing chlorine (bleach,
hydrochloric acid etc.) even diluted, to clean the steel
surfaces. Recommended that you use only stainless steel
maintenance spray.
● Do not use corrosive substances (i.e. muriatic acid) to clean
the floor underneath the appliance.
10
WASTE PLUG
SUCTION FILTER
MAINTENANCE, INSPECTIONS, CHECKS AND
CLEANING
Routine cleaning
General Cleaning of the machine and
surrounding area
Mechanical protection devices
Check condition and for any deformation,
loosening or removed parts.
Make the general cleaning of washing arms
(FigureB)
Control and Machine structure
Check mechanical part for any breakage or
deformation, tightening of screws. Check
readability and condition of words, stickers and
symbols and restore if necessary.
Electrical connection cable and plug
Check connection cable (replace it if necessary)
and plug.
5.1 WASHING ARMS GENERAL CLEANING
The upper and lower washing arms placed in the machine must
be cleaned periodically at the end of each month. This process
can be done by removing the washing arms from the bolts
manually which is connecting the arms to the machine.
Afterwards, the jet nuts should be cleaned by removing them
from the washing arms. As shown at the FIGURE C, washing and
rinsing arms should be dissassembled and their inside should
be cleaned with water. Any accumulation of dirt in jets mouths
should be cleaned with a suitable fine-edged objects. Jets are
very delicate and they are likely to be affected by increases in
hardness of the rinsing water. Sedimentary and hard water will
led clogging very quickly. Therefore, rinse arms must be
checked periodically and
cleaned if needed.
directly affecting the washing performance of the machine
PIVOT PIN RING
RINSING JET NUT
RINSING JET
RINSING ARM
(FIGURE C)
FREQUENCY
Daily
Mounthly
Yearly
Yearly
This is a factor that
.
WASHING WASHING
ARM JET ARM JET NUT
WASHING ARM
