nimlok compact Pop-Up Setup Instructions page 5

BUBBLE PANELS
SHADOWBOX ASSEMBLY
TOP
2700 CHANNEL BAR
SIDE
BOTTOM
2
While holding up the Top, insert the Sides
between the Top & Bottom.
Attach the Double-Bulb
Fixtures to the frame where
the bubble panel will be
placed.
FRAME
BACK
CLEAR SHELVES
Apply the Bubble Panel's magnets
to the Channel Bars and allow
the panel to bow forward.
1 After installing the Channel Bars, insert
the Top & Bottom into the Frame.
3
To finish the installation, slide in
the Clear Shelves & attach the Back.
2700 CHANNEL BAR
