REPTIL'US Thermostat DT Control Timer Manual page 5

A. Start time setting: Press SET key until display ​ L 1​ and ​ F ROM​ icon flashing, at the same time display the default time, press UP or DOWN
key to set the hour;
After hour set, press SET key to set the minute, press UP or DOWN key to set the value;
B. End time setting: When start time is already finished, press SET key and then ​ T O​ icon flashing, you can set end time in the same
method.
4.2 Second timing control L2: The same operation with first timing control L1.
7. Real-time setting:
Press SET key, icon flashing and display current hour set value, press UP or DOWN key to adjust the system time;
Press SET key and then set minute value in the same method.
8. Daytime time setting:
A. Start time setting: Press SET key,
or DOWN key to modify the value.
After hour set, press SET key to set the minute, press UP or DOWN key to set the value;
B. End time setting: When start time is already finished, press SET key and then ​ T O icon flashing, you can set end time with the same
method of start time setting.
9. Night time time setting:
A. Start time setting: Press SET key,
or DOWN key to modify the value.
After hour set, press SET key to set the minute, press UP or DOWN key to set the value;
B. End time setting: When start time is already finished, press SET key and then ​ T O icon flashing, you can set end time with the same
method of start time setting.
Tips:
1. If current menu don't need adjustment, press SET key directly to switch to next menu, press SET key for 3 seconds to exit and save
settings.
2. Parameters of temperature and timer can be recycled view by pressing UP or DOWN key in normal status.
3. The product returns to normal working condition automatically without any key operate in 15 seconds.
4. Parameter adjustment: Press UP or DOWN key and hold, enter into quickly adjusting state.
Set high and low limits of the set temperature:
In normal working status:
A. High limit: Press UP key for 5 seconds to display current high temperature limit setting(50℃), and then press UP or DOWN key to
modify the set value.
B. Low limit: Press DOWN key for 5 seconds to display original low temperature limit setting(0℃), and then press UP or DOWN key to
modify the set value.
For example: if the limits are default value, the set temperature can be adjusted between 0~50℃; if the high limit is 30C, low limit is 10C,
the set temperature can only be adjusted between 10~30℃
Controlling function:
Heat controlling function:
Heating systems works if the measuring temperature ≤ the set temperature - the temperature difference
Heating systems stops working if the measuring temperature ≥ the set temperature
Cool controlling function:
Cooling systems works if the measuring temperature ≥ the set temperature + the temperature difference
Cooling systems stops working if the measuring temperature ≤ the set temperature
Timing controlling function:
FROM:​ timing of turning on light; ​ T O​ : timing of turning off light
If the system time is during FROM time and TO time, the light will light when timing setting has adjusted and saved. For example, original
timing starting time is 8:30, original timing ending time is 18:30, new timing starting time is 6:00, new timing ending time is 18:00, the
system time is 7:00, you will see the light is on. If not, the light is off.
Others:
1. Over temperature alarm: upper part of
below situation:
the measuring temperature ≥ the set temperature + Alarm over temperature
the measuring temperature ≤ the set temperature - Alarm over temperature
2. Exceed temperature measuring limits alarm: with "drops" alarm sounds at the same time.
the measuring temperature ＜0.0℃, display LLL: super low temperature;
the measuring temperature ＞50.0℃, display HHH: super high temperature;
3. Probe fault alarm: when probe have open circuit or short circuit faulty, display error message of probe faulty "ERR"
➢ Mute alarming manually:
st ​ nd ​
the 1​ and 2​ alarm can be muted by pressing any key, but probe fault alarm sound cannot eliminate.
Press UP or DOWN key at the same time for 3 sec or more, the menu is available to choose whether to eliminate alarm sound, AL: have
alarm sounds, NO: have no alarm sounds.
C. You can choose one and press SET to save and exit.
➢
Socket output control load:
I: heat/cool output; II: timer output, such as lighting or oxygen pump.
icon flashing, at the same time ​ F ROM flashing and display default hour value, press UP
and
icon flashing, at the same time ​ F ROM flashing and display default hour value, press UP
and
icon rapid flashing with "drops" alarm sounds and display the measuring temperature in
