NBXR463EBWW – Hotpoint 6.0 Cu. Ft. Extra-Large Capacity Electric Dryer

Dryer Dimensions (in inches)

23-1/2

25-3/4

25-1/2*

5-1/4

Side View

*24-1/2" from the edge of the side panel to the front.

25-1/2" from front to edge of end caps.

Specification Revised 3/03

11-1/2

2-1/2

Rear View

Exhaust Options:

4-way via rear, right, left and bottom.

Circuit Requirements:

An individual, properly-grounded branch circuit, protected by a 30-amp circuit

breaker or a time-delay fuse, is required.

Electric Dryer Rating:

208/240V, 5600W, 60Hz, 24 Amp

Installation Information: For complete information, see installation instructions

packed with product for current dimensional data.

3-1/2

Listed by

Underwriters

Laboratories
