Hoshizaki KML-400MAE Final Parts List

Modular crescent cuber
Hide thumbs Also See for KML-400MAE:

Advertisement

Quick Links

Download this manual See also: Instruction Manual
MODULAR CRESCENT CUBER
KML-400MAE
KML-400MWE
HOSHIZAKI
MODEL
(FINAL) PARTS LIST
NO.
71121
ISSUED:
JAN. 26, 1998
REVISED: SEPT. 12, 2000

Advertisement

loading

Related Manuals for Hoshizaki KML-400MAE

Summary of Contents for Hoshizaki KML-400MAE

  • Page 1 MODULAR CRESCENT CUBER KML-400MAE KML-400MWE (FINAL) PARTS LIST HOSHIZAKI MODEL 71121 ISSUED: JAN. 26, 1998 REVISED: SEPT. 12, 2000...
  • Page 2 KML-400MAE MARCH, 1997 DEC., 1997 APRIL, 1998 JUNE, 1998 OCT., 1998 DEC., 1998 KML-400MWE MARCH, 1997 JAN., 1998 MAY, 1998 JUNE, 1998 OCT., 1998 DEC., 1998...

  • Page 3: Material Abbreviations

    ALUMINUM Aluminum COPPER Copper PLASTIC Acrylonitrile -butadiene - styrene Polyacetal Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PTFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride RUBBER Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene SI.R...
  • Page 4 Phillips Truss Machine Screw Phillips Pan Head Machine Screw Phillips Flat Head Machine Screw Phillips Pan Head Machine Screw with Split Lock Washer Phillips Pan Head Machine Screw with Split Lock Washer and Flat Washer Phillips Truss Head Tapping Screw (Correspond to Type A) Phillips Truss Head Tapping Screw (Correspond to Type B) Phillips Truss Head Tapping Screw (Correspond to Type C) Phillips Truss Head Tapping Screw (Special)

  • Page 5: Ice Cuber Assembly

    KML-400MAE A. ICE CUBER ASSEMBLY G-0, H-0, H-1, H-2...
  • Page 6 KML-400MAE A. ICE CUBER ASSEMBLY H-3, J02385M-J02784B...
  • Page 7 KML-400MAE A. ICE CUBER ASSEMBLY J02785C--...
  • Page 8 KML-400MAE MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONTROL BOX ASSEMBLY T2 SCREW LABEL LOCATION TOP PANEL ASSEMBLY FRONT PANEL ASSEMBLY TRUSS HEAD SCREW EVAPORATOR CASE CONTROL BOX COVER T2 SCREW SQUARE WASHER SCREW - GROUNDING JUNCTION BOX COVER T2 SCREW...
  • Page 9 KML-400MAE MODEL INDEX DESCRIPTION CAPILLARY RING TOP INSULATION FRONT INSULATION SIDE PANEL (R) T2 SCREW COVER - MANUAL FILL TRUSS HEAD SCREW LOUVER (B) TAPPING SCREW (BLACK) AIR FILTER (B) BUSHING WIRE SADDLE THUMBSCREW LOUVER (C) AIR FILTER (C) GASKET...
  • Page 10 KML-400MWE A. ICE CUBER ASSEMBLY G-0, H-1, H-2, H-3...
  • Page 11 KML-400MWE A. ICE CUBER ASSEMBLY H-4, J00466M-J00615B...
  • Page 12 KML-400MWE A. ICE CUBER ASSEMBLY J00616C--...
  • Page 13 KML-400MWE MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONTROL BOX ASSEMBLY T2 SCREW LABEL LOCATION TOP PANEL ASSEMBLY FRONT PANEL ASSEMBLY TRUSS HEAD SCREW EVAPORATOR CASE CONTROL BOX COVER T2 SCREW SQUARE WASHER SCREW - GROUNDING JUNCTION BOX COVER BULB HOLDER SPACER THUMBSCREW BIN CONTROL COVER...
  • Page 14 KML-400MWE MODEL INDEX DESCRIPTION FRONT INSULATION SIDE PANEL (R) T2 SCREW COVER - MANUAL FILL TRUSS HEAD SCREW LOUVER (B) TAPPING SCREW (BLACK) BUSHING WIRE SADDLE THUMBSCREW LOUVER (C) GASKET GASKET THERMOSTAT BRACKET EXTENSION A. ICE CUBER ASSEMBLY TITLE MATERIAL OR PART MODEL NUMBER...

  • Page 15: Refrigeration Circuit

    KML-400MAE B. REFRIGERATION CIRCUIT G-0, H-0, H-1, H-2...
  • Page 16 KML-400MAE B. REFRIGERATION CIRCUIT H-3, J-0...
  • Page 17 KML-400MAE MODEL INDEX DESCRIPTION CONDENSER SUPPORT T2 SCREW CONDENSER T2 SCREW BARRIER T2 SCREW SHROUD T2 SCREW COMPRESSOR BOLT SPACER GROMMET MOTOR PROTECTOR PROTECTOR HOLDER FAN MOTOR BRACKET HEX HEAD BOLT W/WASHER (LF) FAN MOTOR SELF-LOCKING NUT FAN BLADE DRIER...
  • Page 18 KML-400MAE MODEL INDEX DESCRIPTION PRESSURE SWITCH PRESSURE SWITCH BRACKET T2 SCREW ACCESS VALVE COPPER TUBE (A) - HIGH SIDE COPPER TUBE (A1) - HIGH SIDE COPPER TUBE (B) - HIGH SIDE COPPER TUBE (C) - HIGH SIDE COPPER TUBE (D) - HIGH SIDE...
  • Page 19 KML-400MAE MODEL INDEX DESCRIPTION INSULATED RUBBER TUBE FRAME (A) T2 SCREW FRAME (B) T2 SCREW CABLE TIE LINE VALVE BRACKET INSULATION TUBE INSULATION TUBE INSULATION TUBE INSULATION TUBE INSULATION TUBE EVACUATION TUBE COPPER TUBE (D2) - HIGH SIDE INSULATION TUBE INSULATION TUBE B.
  • Page 20 KML-400MWE B. REFRIGERATION CIRCUIT G-0, H-1, H-2, H-3...
  • Page 21 KML-400MWE B. REFRIGERATION CIRCUIT H-4, J-0...
  • Page 22 KML-400MWE MODEL INDEX DESCRIPTION CONDENSER SUPPORT T2 SCREW CONDENSER - WATER COOLED HEX HEAD BOLT W/WASHER (LF) REAR PANEL (B) T2 SCREW COMPRESSOR BOLT SPACER GROMMET MOTOR PROTECTOR PROTECTOR HOLDER FAN MOTOR BRACKET BOLT & WASHER ASSEMBLY FAN MOTOR SCREW WASHER FAN BLADE DRIER...
  • Page 23 KML-400MWE MODEL INDEX DESCRIPTION COIL - VALVE BOLT TRUSS HEAD SCREW PRESSURE SWITCH PRESSURE SWITCH BRCKT. T2 SCREW ACCESS VALVE COPPER TUBE (A) - HIGH SIDE COPPER TUBE (B) - HIGH SIDE COPPER TUBE (C) - HIGH SIDE COPPER TUBE (D1) - HIGH SIDE COPPER TUBE (D2) - HIGH SIDE COPPER TUBE (E) - HIGH SIDE STRAINER...
  • Page 24 KML-400MWE MODEL INDEX DESCRIPTION COPPER TUBE (B) HOLDER / EXPANSION VALVE - 3/8 CLAMP EXPANSION VALVE COVER (A) EXPANSION VALVE COVER (B) THERMISTOR HOLDER - THERMISTOR INSULATION - THERMISTOR (A) INSULATION - THERMISTOR (B) INSULATED RUBBER TUBE FRAME (A) T2 SCREW FRAME (B) T2 SCREW CABLE TIE...
  • Page 25 KML-400MWE MODEL INDEX DESCRIPTION THERMOSTAT TRUSS HEAD SCREW INSULATION TUBE B. REFRIGERATION CIRCUIT TITLE MATERIAL OR PART MODEL NUMBER NUMBER 440664-03 7C31-0306 L=100 7762-1020 REQUIRED NUMBER...

  • Page 26: Water Circuit

    KML-400MAE, MWE C. WATER CIRCUIT G-0, H-0, H-1, H-2, H-3, H-4...
  • Page 27 KML-400MAE C. WATER CIRCUIT J02385M-J02784B...
  • Page 28 KML-400MWE C. WATER CIRCUIT J00466M-J00615B...
  • Page 29 KML-400MAE C. WATER CIRCUIT J02785C--...
  • Page 30 KML-400MWE C. WATER CIRCUIT J00616C--...
  • Page 31 FLANGE INSULATION (E) VINYL HOSE CONNECTING PIPE HOSE CLAMP CUBE GUIDE (A) PUMP HOSE RUBBER RING BYPASS HOSE HOSE CLAMP SOLENOID VALVE TRUSS HEAD SCREW KML-400MAE C. WATER CIRCUIT TITLE MATERIAL OR MODEL NUMBER COPPER COPPER J248-033 J248-072 EPDM SANTOPRENE...
  • Page 32 INSULATION (B) - PUMP BRACKET HOSE CLAMP HOSE CLAMP INSULATION (A1) - BYPASS HOSE INSULATION (A2) - BYPASS HOSE INSULATION HOSE FLOAT SWITCH SPACER ELBOW DRAIN O-RING KML-400MAE C. WATER CIRCUIT TITLE MATERIAL OR MODEL NUMBER 4X16, SS 163795 4X8, SS 4X12, SS...
  • Page 33 MODEL INDEX DESCRIPTION WATER SUPPLY PIPE T2 SCREW RUBBER GASKET WATER VALVE BRACKET T2 SCREW WATER VALVE SPRAY TUBE SPRAY GUIDE (A) WATER SUPPLY TUBE PLUG WATER SUPPLY TEE FLANGE INSULATION (E) VINYL HOSE CONNECTING PIPE HOSE CLAMP CUBE GUIDE (A) PUMP HOSE RUBBER RING BYPASS HOSE...
  • Page 34 MODEL INDEX DESCRIPTION ARROW LABEL SOLENOID COVER T2 SCREW PUMP TRUSS HEAD SCREW FLOAT SWITCH T2 SCREW FLOAT SWITCH BRACKET T2 SCREW FLOAT SWITCH COVER T2 SCREW VINYL HOSE SILICONE HOSE BUSHING WIRE SADDLE WELL NUT INSULATION (A) - PUMP BRACKET TOOTH WASHER T2 SCREW INSULATION (B) - PUMP BRACKET...

  • Page 35: Control Box Assembly

    KML-400MAE D. CONTROL BOX ASSEMBLY G-0, H-0...
  • Page 36 KML-400MAE D. CONTROL BOX ASSEMBLY H-1, H-2, H-3, J-0...
  • Page 37 KML-400MAE MODEL INDEX DESCRIPTION CONTROL BOX CAPACITOR CAPACITOR - STARTING STRAP T2 SCREW STARTER T2 SCREW RELAY TAPPING SCREW THERMOSTAT TRUSS HEAD SCREW TOGGLE SWITCH TOGGLE SWITCH TRANSFORMER T2 SCREW CONTROLLER BOARD BOARD SUPPORT MAGNETIC CONTACTOR BRACKET T2 SCREW CAPACITOR...
  • Page 38 KML-400MWE D. CONTROL BOX ASSEMBLY G-0, H-1...
  • Page 39 KML-400MWE D. CONTROL BOX ASSEMBLY H-2, H-3, H-4, J-0...
  • Page 40 040-0001-20 434923-01 7P31-0408 LY2F 120 VAC 406132-07 431415-01 A30-3815-00 4A0824-01 7C31-0408 7563K6 443119-01 8966K211 4A0985-01 26D285H 3A0172-01 7P31-0408 MY9KM910 2U0127-01 HOSHIZAKI-001 2A0836-01 CBLS37-M 4A0336-03 VC20 428393-01 BW9154 428393F01 7P31-0408 OCB-500 428394-02 OCB-625 428394-03 OCB-875 428394-04 PES FILM 434934-01 PES FILM...

  • Page 41: Label Location

    KML-400MAE E. LABEL LOCATION G-0, H-0...
  • Page 42 KML-400MAE E. LABEL LOCATION H-1, H-2, H-3, J02385M-J02784B...
  • Page 43 KML-400MAE E. LABEL LOCATION J02785C--...
  • Page 44 LABEL - R22 CAUTION LABEL (F) CAUTION LABEL (K) LABEL - AIR FILTER INSTRUCTION LABEL WARNING LABEL - MANUAL FILL LABEL – CONTROL BOARD RATING LABEL KML-400MAE E. LABEL LOCATION TITLE MATERIAL OR MODEL NUMBER PETP FILM PETP FILM PETP FILM...
  • Page 45 KML-400MWE E. LABEL LOCATION G-0, H-1...
  • Page 46 KML-400MWE E. LABEL LOCATION H-2, H-3, H-4, J00466M-J00615B...
  • Page 47 KML-400MWE E. LABEL LOCATION J00616C--...
  • Page 48 MODEL INDEX DESCRIPTION EMBLEM MODEL NUMBER LABEL LABEL - PENGUIN - HA (R) MAINTENANCE LABEL WIRING LABEL NAMEPLATE INSTRUCTION SHEET MANUAL LABEL TAG - WARNING: ELECTRICAL CONNECTION LABEL - R22 CAUTION LABEL (F) CAUTION LABEL (K) INSTRUCTION LABEL WARNING LABEL - MANUAL FILL LABEL –...
  • Page 49 KML-400MAE, MWE F. TOP PANEL ASSEMBLY G-0, H-0, H-1, H-2, H-3, H-4, J-0...
  • Page 50 KML-400MAE, MWE MODEL INDEX DESCRIPTION TOP PANEL GASKET GASKET (A) INSULATION F. TOP PANEL ASSEMBLY TITLE MATERIAL OR PART MODEL NUMBER NUMBER 213543-01 427014-04 NORMOUNT V710 324859-03 PE FOAM 438012-01 REQUIRED NUMBER...

  • Page 51: Front Panel Assembly

    KML-400MAE G. FRONT PANEL ASSEMBLY G-0, H-0, H-1, H-2, H-3, J02385M-J02784B...
  • Page 52 KML-400MAE G. FRONT PANEL ASSEMBLY J02785C--...
  • Page 53 KML-400MAE MODEL INDEX DESCRIPTION FRONT PANEL (A) INSULATION - FRONT PANEL FOAM SEAL FOAM SEAL FOAM SEAL FOAM SEAL TAPE - NORTON SEAL G. FRONT PANEL ASSEMBLY TITLE MATERIAL OR PART MODEL NUMBER NUMBER 2A0990-01 2A1455-01 PE FOAM 3A0673-01 L=370...
  • Page 54 KML-400MWE G. FRONT PANEL ASSEMBLY G-0, H-1, H-2, H-3, H-4, J00466M-J00615B...
  • Page 55 KML-400MWE G. FRONT PANEL ASSEMBLY J00616C--...
  • Page 56 KML-400MWE MODEL INDEX DESCRIPTION FRONT PANEL (A) INSULATION - FRONT PANEL FOAM SEAL FOAM SEAL FOAM SEAL FOAM SEAL TAPE - NORTON SEAL G. FRONT PANEL ASSEMBLY TITLE MATERIAL OR PART MODEL NUMBER NUMBER 2A0990-01 2A1455-01 PE FOAM 3A0673-01 L=370 4A0661L01 L=450 4A0661L01...
  • Page 57 KML-400MAE, MWE H. ACCESSORIES G-0, H-0, H-1, H-2, H-3, H-4, J-0...
  • Page 58 MODEL INDEX DESCRIPTION INSTRUCTION MANUAL UNIVERSAL BRACE KML-400MAE, MWE TITLE MATERIAL OR MODEL NUMBER PAPER J. ACCESSORIES PART REQUIRED NUMBER NUMBER 91A1BA10A 4A0363-01...
